GB WP 76
On button
Off button
Delayed start button
Press the button repeatedly to delay the
start of the programme by 3, 6 or 9 hours.
Then press the START button. The
dishwasher will start at the set time.
Detergent setting upon initial use and when using a different type of
detergent
1. Select the third programme in the relative table.
2. Press the START button for approx. 7 sec. to change the display.
3. Using the START button, select the desired detergent:
"3h" = 2in1, "6h" = 3in1, "9h" = other combined action detergents
(in this way, the rinse aid and/or salt indicator is deactivated). All 3
LEDs light up = Powder detergent (factory setting).
4. Switch the appliance off and then switch it on again. The selected
detergent type will be indicated on the display by the corresponding
LEDs for approx. 3 seconds.
P
Programmes
1
Auto Sensor 50-65°C
2
Rapid
3
2)
Bio
4
Intensive
5
Power Clean 70°C
1) Programme data obtained in conformity with European standard EN 50242. Values may vary in relation to usage, e.g.
different loads, options, different sensor settings (only with sensor programmes), different water supply temperatures, as well
as water hardness and power supply voltage.
2) Reference programme for energy label in compliance with EN 50242. - Important information for Test Laboratories: for
detailed information on the EN/Standard loading comparison test and other tests, contact the following address:
"nk_customer@whirlpool.com".
Whirlpool is a registered trademark of Whirlpool USA
Before using the dishwasher, read the
installation and maintenance instructions carefully!
1. OVERVIEW
Table 1.1.

Programme chart

Available
Loading instructions
options
Recommended programme for
routine washes, with dried-on food
(e.g. EN 50242).
Lightly soiled crockery, with no dried-
40°C
on food.
50°C
Normally soiled crockery.
Recommended programme for
70°C
heavily soiled crockery, especially
suitable for pans and saucepans.
Recommended programme for
heavily soiled crockery, especially
suitable for pans and saucepans.
Intensive wash with additional water
jets.
Programme selection button
Press the button repeatedly until the desired programme
indicator lights up.
Start button
Switches "on" when the dishwasher is operating.
Flashes when a fault occurs. Switches off at the end of
the programme.
START button RESET function:
Press this button for at least 2 seconds; the selected
programme and options are cancelled. Main failure
displays (repeated flashing of the START indicator lamp)
can be cancelled by RESETTING. Detailed instructions
are given in chapter 5 "What to do, if...".
Rinse aid level indicator and salt level indicator
These indicator lamps light up when rinse aid or salt
need to be added.
Add just before starting a wash programme.
Detergent
Consumption
dispenser
large small Litres
X X 11-16 1.10-1.50 100-130 ±
X — 10.0
X X 14.0
X X 14.0
X X 16.0
5019 396 01064
1)
kWh Minutes
1)
1)
0.65 30 ±
1)
1.05 195 ±
1)
1.55 155 ±
1)
1.80 220 ±
