Specifications; Ordering Information - Avocent SwitchView Specifications

SwitchView
SwitchView DT
SwitchView MP
SwitchView SC
SwitchView OSD

Specifications

SwitchView, SwitchView DT, SwitchView MP, SwitchView OSD, SwitchView SC
MECHANICAL Height
SwitchView, SwitchView MP 1.9" (4.83 cm)
SwitchView OSD 1.7" (4.5 cm)
SwitchView DT 1.9" (4.83 cm)
SwitchView SC 2.7" (6.86 cm)
ENVIRONMENTAL / POWER / HARDWARE
Operating Temperature
Storage Temperature
Power Requirements
Supported Hardware - Computer
Supported Hardware - Video Modes
Supported Hardware - Peripherals
Warranty

Ordering Information

SWITCH
SwitchView
12025 Single user, 2-port w/ (2) CPS2-6A cables
12045 Single user, 4-port w/ (2) CPS2-6A cables
10025 Single user, 2-port w/o cables
10045 Single user, 4-port w/o cables
SwitchView MP
14085-AM Single user, 4-port
SwitchView DT
14045 Single user, 4-port
SwitchView SC
10040-SC Single user, 4-port
SwitchView OSD
10085-AM Single user, 8-port
Width Depth
8.1" (20.6 cm) 5" (12.7 cm)
17.2" (43.7 cm) 6.5" (16.51 cm)
11" (27.94 cm) 11" (27.94 cm)
8.1" (20.6 cm) 5" (12.7 cm)
41º (5ºC) to 104º (40ºC)
-4º (-20ºC) to 122º (50ºC)
SwitchView, SwitchView DT, SwitchView SC: 6 VDC @ 700 mA (opt.)
SwitchView MP: 100-240 VAC, 50-60 Hz (external power)
SwitchView OSD: 100-240 VAC, 50-60 Hz (internal power)
SwitchView, SwitchView DT, SwitchView SC: IBM PC/AT, PS/2
and 100% compatibles
SwitchView MP: IBM PC/AT, PS/2 and 100% compatibles, Sun, USB
SwitchView SC: VGA and SVGA maximum 1600 x 1200 @ 75 Hz res.
SwitchView OSD: VGA and SVGA maximum 1600 x 1200 @ 85 Hz res.
SwitchView, SwitchView DT: VGA and SVGA maximum 1600 x 1200
@ 85 Hz res.
SwitchView MP: VGA, Sun and Sun 13W3 maximum 1600 x 1200
@ 85 Hz res.
SwitchView, SwitchView DT: Logitech MouseMan Wheel, Logitech
TrackMan Marble Wheel, Logitech TrackMan Marble FX, Microsoft
Explorer Mouse, Microsoft IntelliMouse family
SwitchView MP: PS/2 keyboard with PS/2 mouse, PS/2 keyboard with
serial (9 pin) mouse, Sun keyboard and Sun mouse, USB keyboard
and mouse, Microsoft Explorer mouse, Microsoft IntelliMouse Family,
IBM Scrollpoint, Logitech Mouseman Wheel, Logitech Trackman
Marble wheel, Logitech Marble FX and Kensington 4 button mouse,
Sun Type 5 and Type 6
SwitchView SC, SwitchView OSD: PS/2 keyboard, PS/2 mouse,
Microsoft IntelliMouse (PS/2 only)
Two Year
CABLES
SwitchView, SwitchView DT, SwitchView SC
CPS2 6 feet
SwitchView OSD
CPS2 6 feet
CIS 8, 15 feet
SwitchView MP
CUFC 6 feet
VGA, PS/2 kybd, AT kybd,
PS/2 mouse and serial mouse
CIFCA 4, 8, 15, 30 feet
VGA, PS/2 kybd, PS/2 mouse
CUSB 4, 8, 12 feet
VGA, USB kybd & mouse
CWSN 4, 8, 15, 30 feet
13W3, Sun kybd & mouse
CVSN 4, 8, 15, 30 feet
VGA, Sun kybd & mouse
Weight
0.9 lbs (0.4 kg)
4.2 lbs (1.91 kg)
4.2 lbs (1.9 kg)
1.1 lbs (0.5 kg)
