Data sheet | HP MSM Controller Series
HP MSM Controller Series (continued)
Specifications
HP MSM760 Premium Mobility Controller (J9420A)
I/O ports and slots
2 RJ-45 autosensing 10/100/1000 ports; Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T:
full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
Physical characteristics
1 RJ-45 serial console port
17.32(w) x 15.38(d) x 1.75(h) in. (43.99 x 39.07 x 4.45 cm) (1U height)
Services
Refer to the HP website at hp.com/networking/services for details
on the service-level descriptions and product numbers. For details
about services and response times in your area, please contact
your local HP sales office.
Weight
13.45 lb (6.1 kg)
Mounting and enclosure
Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
Environment
Operating temperature 41°F to 104°F (5°C to 40°C)
Nonoperating/Storage -40°F to 149°F (-40°C to 65°C)
temperature
Operating relative humidity 15% to 80%, noncondensing
Nonoperating/Storage 15% to 80%, noncondensing
relative humidity
Electrical characteristics
Frequency 50/60 Hz
Maximum heat dissipation 434 BTU/hr (457.87 kJ/hr)
AC voltage 100–240 VAC
Current 2/1 A
Maximum power rating 127 W
Safety
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2
No. 60950-1
Emissions
FCC part 15 Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003
Features
Supported:
– IEEE 802.11 n/a/b/g access points and/or access devices
– 40 to 200 access points and/or access devices
– MSM firmware releases prior to MSM v5.7: 1,000 simultaneous
– MSM v5.7 and later: 2,000 simultaneous guest access users
Included services:
– Plug-and-play AP management and WLAN management
– Guest access
– Captive portal
– PCI DSS compliance for wireless PoS traffic
– Support for Real-Time Location Services (RTLS)
– Advanced fast roaming with VoWLAN support
– Mobility Traffic Manager (MTM)
– Support for up to 64 VSC profiles
– Unified policy enforcement and network visibility
Notes Not all services are supported with the Virtual Controller feature.
Services Refer to the HP website at hp.com/networking/services for details
on the service-level descriptions and product numbers. For details
about services and response times in your area, please contact
your local HP sales office.
(in increments of 10 or 40)
guest access users upgradable in increments of 250 per 40-AP
license pack, up to a maximum of 2,000 guest access users
with base product
HP MSM760 Access Controller (J9421A)
2 RJ-45 autosensing 10/100/1000 ports; Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T:
full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
1 RJ-45 serial console port
17.32(w) x 15.38(d) x 1.75(h) in. (43.99 x 39.07 x 4.45 cm) (1U height)
Refer to the HP website at hp.com/networking/services for details
on the service-level descriptions and product numbers. For details
about services and response times in your area, please contact
your local HP sales office.
13.45 lb (6.1 kg)
Mounts in an EIA-standard 19 in. Telco rack or equipment cabinet
(hardware included); horizontal surface mounting only
41°F to 104°F (5°C to 40°C)
-40°F to 149°F (-40°C to 65°C)
15% to 80%, noncondensing
15% to 80%, noncondensing
50/60 Hz
434 BTU/hr (457.87 kJ/hr)
100–240 VAC
2/1 A
127 W
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2
No. 60950-1
FCC part 15 Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003
Supported:
– IEEE 802.11 n/a/b/g access points and/or access devices
– 40 to 200 access points and/or access devices
(in increments of 10 or 40)
– MSM firmware releases prior to MSM v5.7: 1,000 simultaneous
guest access users upgradable in increments of 250 per 40-AP
license pack, up to a maximum of 2,000 guest access users
– MSM v5.7 and later: 2,000 simultaneous guest access users
with base product
Included services:
– Plug-and-play AP management and WLAN management
– Guest access
– Captive portal
– PCI DSS compliance for wireless PoS traffic
– Support for Real-Time Location Services (RTLS)
– Standard Layer 2 roaming with VoWLAN support
– Support for up to 16 VSC profiles
– Unified policy enforcement and network visibility
– Virtual controller (up to five MSM765 zl controllers and 800 APs
with resiliency)
Please refer to the user documentation for more detail.
Refer to the HP website at hp.com/networking/services for details
on the service-level descriptions and product numbers. For details
about services and response times in your area, please contact
your local HP sales office.
