American Standard Princeton Fixture-Mounted Bidet Fitting 4508.400 Specification Sheet

4508.401 Shown
TRANSFER VALVE
(FOR FLUSHING
BIDET OUTLINE
IS SYMBOLIC
ADJ. 32 to 57mm
(1-1/4 TO 2-1/4)
DOUCHE SPRAY
98mm
(3-7/8)
140mm
(5-1/2)

GENERAL DESCRIPTION:

Cast brass valve bodies. 1/4 turn washerless ceramic disc
valve cartridges. Diverter controls water flow between douche
spray and flushing rim. Douche spray has built-in spray height
adjustment. 20 " (500mm) long flexible stainless steel drain
cable is pre-assembled to lift rod assembly. Metal Speed
Connect™ drain body with 1-1/4 " (32mm) tail piece.
SUGGESTED SPECIFICATION:
Two handle deck-mount bidet fitting with matching pop-up drain shall feature solid brass construction. Shall also feature 1/4 turn
washerless ceramic disc valve cartridges. Shall also feature a metal drain body with stainless steel cable actuation. Fitting shall
be American Standard Model #7038.40_.___.
© 2008 AS America Inc.
RIM OR SPRAY)
22mm
(7/8) DIA.
54mm
(2-1/8)
DIA.
35mm
(1-3/8)
DIA.
FINISHED
WALL
32mm
(1-1/4)
O.D. TAILPIECE
FIXTURE-MOUNTED BIDET FITTING
MODEL NUMBER:
4508.401 Fixture-Mounted Bidet Fitting
Vacuum breaker. Metal Speed Connect™ Pop-up drain.
Metal lever handles.
4508.400 Fixture-Mounted Bidet Fitting
Less vacuum breaker. Metal Speed Connect™ Pop-up
drain. Metal lever handles.
(C)
38mm
(1-1/2) DIA.
32mm
(1-1/4) MAX.
FINISHED
FLOOR

PRODUCT FEATURES:

Brass Construction:
applications. Ideal for prolonged contact with water.
Ceramic Disc Valve Cartridges:
smooth handle operation and drip-free performance.
Exclusive Speed Connect Metal Drain:
• Fewer Parts - installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in
tight spaces.
Choice of Finishes:
and Satin Nickel (295) finishes.
D23
PRINCETON
203mm
(8)
DIVERTER AND
VACUUM BREAKER
ASSEMBLY
(H)
108mm
(4-1/4)
FOR GROUND JOINT
CONNECTION OR 1/2"
O.D. SLIP (INLETS)
REAR VIEW WITH
WALL REMOVED
Durable - Excellent in high use
Assures a lifetime of
Available in Polished Chrome (002)
