GPS&GPRS TRACKING SYSTEM
MODULE: GT3000 SERIES
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT3000 SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for PORTMAN GT3000 SERIES

Summary of Contents for PORTMAN GT3000 SERIES

  • Page 1 GPS&GPRS TRACKING SYSTEM MODULE: GT3000 SERIES User Manual...

  • Page 2: Report Structure

    NTRODUCTION GPS GPRS tracking system GT3000 utilize the GPS tracking function and car alarm functions in one unit. You can monitor the vehicle location and control the car alarm remotely. In addition, the unit will send event report if any trigger occurs. It has built-in 8 outputs and 5 inputs to perform essential alarm functions.
  • Page 3 device, (1) User detail (Device ID, server IP, and port, SMS number, GPRS APN…) (2) In-built Geo-fence definition (up to 5 circular, 5 rectangular and 20 point Geo-fence shapes can be set in the device) (3) Report setting (Time, Distance, Intelligent mode, Temperature, Low battery, Course change…) (4) ALARM report (to enable or disable the event generated by the inputs, e.g.
  • Page 4 GPS cannot be located when the Immediate Geo-fence function is been executed, GT3000 will use the last known position as the origin of the circular Geo-fence zone to perform the protection. US Patten for immediate Geo-fence function is pending. 1.4 S TORE AND FORWARD ABILITY When there is no GPRS service or the server close.
  • Page 5 Enable anti-car jacking: (can be performed at any time) If Server sends anti-car jacking command, the system will enter anti-carjacking mode after the unit received the command. When the anti-carjacking has activated, from the beginning to 30 seconds, the parking light will flash once and horn chirp once interval 10 seconds, from 31 to 60 seconds, the parking light will flash once and...

  • Page 6: Led Indication

    twice. After releasing it, a panic action will be generated. (4) ‘Duty on’ or ‘Duty off’ reports / ‘Status on’ Status off’ reports Press the button (the LED will be temporally stay off) and release it when the LED flashes 3 times.

  • Page 7: Basic Functions

    ASIC FUNCTIONS FUNCTIONS APPLICATIONS GPS receiver will output a complete position, velocity, and time (PVT) solution in the NMEA Version 3.0 protocol GPRS use standard TCP or UDP communicate protocol. If the GPRS GPRS, SMS service is failed, the SMS mode will be turned on for emergency use. In-vehicle Door+ In-vehicle Door- 5 input...

  • Page 8: Status Indicator

    Intelligent report (combine time and distance) Keep alive report Temperature report Speeding report Event Report Low battery report Geo-fence trigger report ALARM trigger report, e.g. PANIC mode, ARM, ignition inputs, etc … History data store 3000 report can be saved in unit, and read from server and pc-setup III.
  • Page 9 A. LOGIN DIALOG WINDOW Select the correct COM port number, then “reset” the unit by pressing the reset button, and next click “OK”. Note that: it is necessary to power on and reset the device soon after click the “ok” button. PC setup program will detect the hardware for 60 seconds.
  • Page 10 C. M AIN INTERFACE 1. [U SER DETAIL If the SIM card is password protected, user can input the “SIM PIN” window to set password of SIM Card. Device ID: Set UNIT ID for the device. IMEI: Any operate with ‘request or request all’ after GPRS power on, the module series...
  • Page 11 number will display automatically, otherwise it displayed with space. Set Access Point Name (APN), User Name, Password. The maximum length of the APN, User name and Password is 49 characters. TCP/UDP address and Port number of the remote server being set, UNIT will send report to these address.
  • Page 12 UNIT can save 3000 reports (3000-1) recently; Click ‘Export’ button can export them with Excel or Text format. Initialize: clear all data in UNIT. Request All: read out the whole existing setting from GT3000. Request: read out the setting in the current page. Apply: transfer the setting to GT3000 in the current pages.
  • Page 13 2. [G FENCE Four Circular Geofence and one self-geofence: Circular Geofence must set origin and radius: Origin format :N2446.5321E12120.4231; N2446.5321 is latitude, E12120.4231 is longitude. Radius from 0.1 km to 1000km.
  • Page 14 Five rectangular geofence: Set two points position, the point format is N2446.5321E12120.4231; With two points, generate one rectangle. Unit will detect whether in rectangle. When unit enter or leave rectangle, will send one message out. 20 point Geo-fence areas can be set. When UNIT is out of these predefined zones, a report will be generated.
  • Page 15 3. [R EPORT Automatic report can be configured in this section. To activate the function(s), please select “√” in checkbox and fill in data in the textbox. The reports will be summarized as (1) I NTELLIGENT REPORT...
  • Page 16 Parameters: On/Off, Report time when moving, Report time when stop, threshold speed and stop duration. For example: If “√” is selected in the two checkboxes and fill the above data in the textbox, then: The vehicle will send a moving report every 5 minutes when vehicle speed exceed 18km/hr The vehicle will send a stopped report every 1 hours when vehicle speed lower than 18km/hr Even the vehicle speed lower than 18km/hr, and over 5 minutes, unit will send a stop...
  • Page 17 (4) T EMPERATURE REPORT Parameters: On/Off, and min. and max. Temperature. (5) F UEL SENSOR REPORT The fuel sensor is used for calculating current fuel volume, if user selected this item, user can define the value discretionarily. User can set warning fuel level for report. For example, 60 to represent 60% lower level report.
  • Page 18 (8) F IXED DISTANCE REPORT Parameters: On/Off, and distance. (Min. distance is 0.1 km, max. distance is 100 km). (9) S PEEDING REPORT SPEED IS SPEED 1000 Parameters: on/off, and speed (10) ATTERY REPORT Low battery warning report (to alert user when the internal battery level is low) Parameters: On/Off, and warning battery level for report.
  • Page 19 (11) K EEP ALIVE PROCEDURE Parameters: On/Off, and interval / retry times. In order to keep connection in GPRS network, the unit can be set to send short keep alive report to the server in order to prevent the disconnection from the mobile service provider. Send reports after a successful keep alive ACK.
  • Page 20 (12) GPRS DIAL UP PROCEDURE 1) GPRS always one-line Parameters: Reconnect interval While using this mode, when the unit can not searched GPRS signal, system will reconnect GPRS interval a preset value. (e.g.: 1minute) 2) Based on report mode Parameters: Max. reconnect times, reconnect interval While using this mode, the unit will connect to the server when there is a report to send.
  • Page 21 If the GT3000 is not in the GPRS online status, user can send command &&Y02 or &&Y04 to ask unit to connect to server. This command can be sent from any device via SMS; &&Y02: When received this command, system will actively try to connect to server in next 600 seconds.
  • Page 22 4. [A REPORT LARM SETUP Alarm report(s) is also configurable. User can customize the events generated by the in-vehicle input or build in car alarm to be sent to the server. If the item(s) were selected (VALID), the related reports will be sent. Otherwise the report will be ignored even when an event is occurred internally.

  • Page 23: Physical Parameters

    APPENDIX GT3000 S PECIFICATIONS HYSICAL PARAMETERS Enclosure dimensions 88(L)*76(W)*25(H) Unit Weight About 100g LECTRICAL DC Supply voltage 12V OR 24V DC Tolerance voltage － 3 6V Current (GPRS online) 60mA GPRS* Frequency Range (MHz) 850/900/1800/1900 (Be used in GT3000MT/ GT3000FT/GT3000ST) Frequency Range (MHz) 900&1800&1900 or 850&1800&1900 GPRS* (Be used in GT3000XT)
  • Page 24 GPS* Channels 20 parallel tracking Frequency L1-1575 MHz Sensitivity Tracking -159 dBm Acquisition (Cold start) -142 dBm Position accuracy (Horizontal) ＜ 2 .5m CEP autonomous ＜ 2 .0m CEP SBAX Time to first fix Hot start 1 ＜ Warm start 2 ＜...

  • Page 25: Optional Accessories

    PTIONAL CCESSORIES Built in backup battery (optional) Combined Antenna (with GPRS and active GPS) Temperature sensor (optional) PC-setup Cable (optional) Starter kill relay (RL-100) Using wrench to tighten the screw cap of GPS and GPRS antenna and lock the screw cap to fix position, for avoid antenna connect abnormality, user can not using hands to tighten the screw cap.
  • Page 26 responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 27 RELAY...
