GPS&GPRS TRACKING SYSTEM
MODULE: GT3000X4
User Manual
08-03-2011
Version: 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT3000X4 and is the answer not in the manual?

Questions and answers

Related Manuals for PORTMAN GT3000X4

Summary of Contents for PORTMAN GT3000X4

  • Page 1 GPS&GPRS TRACKING SYSTEM MODULE: GT3000X4 User Manual 08-03-2011 Version: 1.1...

  • Page 2: Report Structure

    1. I NTRODUCTION GPS GPRS tracking system GT3000X4 utilize the GPS tracking function and basic car alarm control functions in one unit. You can monitor the vehicle location and control the car alarm remotely. In addition, the unit will send event report if any trigger occurs. It has built-in 4 outputs and 3 inputs to perform essential alarm functions.

  • Page 3: Geo - Fence Function

    User can deactivate the self-Geo-fence at any time by pressing the valet switch again. If the GPS cannot be located when the Immediate Geo-fence function is been executed, GT3000X4 will use the last known position as the origin of the circular Geo-fence zone to perform the protection.
  • Page 4 1.5 TCP SOCKET SUPPORT GT3000X4 supports both UDP and TCP socket communication. The server IP, port number and socket type can be selected from the PC-setup program or remote server command. In addition, the connection can be swap over to any server IP or port (either UDP or TCP) via the air command.

  • Page 5: History Report

    (2) Activate or deactivate Immediate Geo-fence Press the button and release it when the LED flashes once. After releasing it, the LED will stay continuously on to indicate the ‘Immediate Geo-fence’ is on. To deactivate: Press the button (the LED will be temporally off), and release it when the LED flashes once. After releasing it, the LED will then stay continuously off.
  • Page 6 Keep alive procedure (in order keep connection in GPRS network, the unit can be set to send short keep alive report to the server in order to prevent the disconnection from the mobile service provider) 1.12 A IR DOWAND User can via OTA to update firmware for the main unit. ASIC FUNCTIONS FUNCTIONS APPLICATIONS...
  • Page 7 Keep alive report Temperature report Speeding report Event Report Low battery report Geo-fence trigger report ALARM trigger report, e.g. ignition inputs, etc … History data store 3000 report can be saved in unit, and read from server and pc-setup TATUS INDICATOR LED: YSTEM Power indicator.
  • Page 8 A. LOGIN DIALOG WINDOW Select the correct COM port number, then “reset” the unit by pressing the reset button, and next click “OK”. Note that: it is necessary to power on and reset the device soon after click the “ok” button. PC setup program will detect the hardware for 60 seconds.

  • Page 9: Mportant Information

    MPORTANT INFORMATION SIM PIN: If the SIM card is password protected, user can input the “SIM PIN” window to set password of SIM Card. IMEI: Any operate with ‘request or request all’ after GPRS power on, the module series number will display automatically, otherwise it displayed with space. Device ID/Device password: Set UNIT ID and UNIT password for the device.

  • Page 10: Server Information

    NTERNET LOGIN INFORMATION Set Access Point Name (APN), User Name, Password. The maximum length of the APN, User name and Password is 49 characters. ERVER INFORMATION TCP/UDP address and Port number of the remote server being set, UNIT will send report to these addresses.
  • Page 11 Save: save the current configuration setting to a file. Load: load the saved configuration files. Request: read out the setting in the current page. Request All: read out the whole existing setting from GT3000X4. Apply: transfer the setting to GT3000X4 in the current pages.

  • Page 12: Internet Dial - Up :]

    Apply All: transfer the whole setting to GT3000X4. Initialize: clear all data in UNIT. Note that Device ID, GPRS Login and server IP/Port information need to be input correctly in order to make the connection. If the report sending using GPRS connection fails, the report will be sent to the ‘primary’...

  • Page 13: Keep Alive

    1) GPRS always online Parameters: Reconnect interval While using this mode, when the unit can not searched GPRS signal, system will reconnect GPRS interval a preset value. (e.g.: 1minute) 2) Based on report mode Parameters: Max. reconnect times, reconnect interval While using this mode, the unit will connect to the server when there is a report to send.
  • Page 14 Parameters: On/Off, and interval / retry times. In order to keep connection in GPRS network, the unit can be set to send short keep alive report to the server in order to prevent the disconnection from the mobile service provider. Send reports after a successful keep alive ACK.
  • Page 15 3. [ REPORTS FIXED REPORTS (1) I ’ NTELLIGENT HISTORY REPORT RECORD THE REPORT IN THE SYSTEM S FLASH Parameters: On/Off, Report time when moving, Report time when stop, and threshold speed. (Min. speed is 0.1 km/Hr, max. speed is 1000 km/Hr). If “√”...
  • Page 16 (2)-a Local: Enable this item; fix time reports will be sent in local mode. Roaming: Enable this item, fix time reports will be sent in roaming mode. Otherwise, fix time reports will be saved in memory and be sent to server when comeback to local mode. SMS: If this checkbox is selected, fix time reports will be sent through SMS when GPRS is not available.
  • Page 17 The vehicle will send a stopped report every 10minutes when vehicle is stopping. (3) F IXED DISTANCE REPORT Parameters: On/Off, and distance. (Min. distance is 0.1 km, max. distance is 100 km). If fill the above data in the textbox, then: The vehicle will send a distance report every 3km when vehicle is moving.

  • Page 18: I / O Status Report

    Parameters: On/Off, and min. and max. temperature. Set the report will send in local or roaming or through SMS, max./ min. temperature, temperature unit. O STATUS REPORT Local: Enable this item; fix time reports will be sent in local mode. Roaming: Enable this item, fix time reports will be sent in roaming mode.
  • Page 19 (4) C OURSE CHANGE REPORT Enable this item to send a report when the course change is bigger than the value set here (5) B ATTERY REPORT Enable this item to send a report when the external battery level is low The system will ignore the parameter with a value ‘0’...
  • Page 20 CIRUCLAR TYPE ORIGIN FORMAT Four Circular Geofence and one self-geofence: Circular Geofence must set origin and radius: Origin format :N2446.5321E12120.4231; N2446.5321 is latitude, E12120.4231 is longitude.

  • Page 21: Point Type

    Radius from 0.1 km to 1000km. RECTANGULAR TYPE FORMAT Five rectangular geofence: Set two points position, the point format is N2446.5321E12120.4231; With two points, generate one rectangle. Unit will detect whether in rectangle. When unit enter or leave rectangle, will send one message out. (3) P OINT TYPE...
  • Page 22 20 point Geo-fence areas can be set. When UNIT is out of these predefined zones, a report will be generated.
  • Page 23 DC Supply voltage 12V OR 24V DC Tolerance voltage 9V－36V Current (GPRS online) 50mA GPRS Frequency Range (MHz) 850/900/1800/1900 (Be used in GT3000X4-BJ) GPRS multi-slot class 10 GPRS connectivity GPRS mobile station class B SIM card interface 1.8V/3.0V Antenna Impedance 50ohms Channels...

  • Page 24: Optional Accessories

    Hot start 1 ＜1s Warm start 2 ＜35s Cold 3 ＜35s Standard GPS software NMEA message switchable GGA, GSA GSV, VTG, RMC, GLL OMMUNICATION GPRS \SMS\USB BATTERY Build-in backup battery Li-Ion 300mAH NVIRONMENTAL Operating Temperature -20°C to +55°C Storage Temperature -40°C to +85°C CCESSORIES Main unit...
  • Page 25 Using wrench to tighten the screw cap of GPS and GPRS antenna and lock the screw cap to fix position, for avoid antenna connect abnormality, user can not using hands to tighten the screw cap. VI. Federal Communications Commission (FCC) Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment.
  • Page 26 You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. VII Operation is subject to the following two conditions: 1) This device may not cause interference and 2) This device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 27 2-PIN CONNECTOR FOR GPRS/GPS ANT DETECTED RED LED--POWER INDICATOR GREEN LED--GPS INDICATOR YELLOW LED--GPRS INDICATOR PC SETUP BATTERY PORT OPTIONAL RELAY RELAY 1 2 3 4 BLACK GND 4. PURPLE--TRUNK +12 V Fuse 5A TRUNK Fuse Box RED BATTERY OPTIONAL HORN RELAY RELAY WHITE 12V or 24V...
  • Page 28 FCC Regulations: 　This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 29 radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. 　This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation.
