PORTMAN GT2000 Operation Manual

Gps&gprs personal tracking
Hide thumbs

Advertisement

Quick Links

Download this manual
GPS&GPRS PERSONAL TRACKING GT2000
OPERATION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the GT2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PORTMAN GT2000

Summary of Contents for PORTMAN GT2000

  • Page 1 GPS&GPRS PERSONAL TRACKING GT2000 OPERATION MANUAL...

  • Page 2: Brief Introduction

    REV: 2.3 (Standard, GT2000V3.1, GT2000-D2) I. BRIEF INTRODUCTION Personal Tracking System utilizes the GPS and GPRS functions in one unit. You can monitor the vehicle or the people location and set the system remotely. In addition, the unit will send event report if any trigger occurs.
  • Page 3 Call Monitoring: user can send a SMS that included the preset password of the unit. GT-2000 will send “PASS” SMS ACK back, unit will auto answer the phone in the following 5 minutes. Using built-in real time clock to identify the report time, when GPS signal is lost. Hence, if the report is received with “LAST KNOWN”...

  • Page 4: Panel Installation

    III. PANEL INSTALLATION Battery charger PC-setup IV. BUTTON OPERATION: Button Indication Functions Conditions Press power switch Power LED flash 1time/3sec. Power ON Power off button once Low power Power LED normal is green ，if low power then change to red Press power switch Power LED off Power OFF...
  • Page 5 Press button1 for Power LED flash quickly 3 times Send SOS report No incoming call is 2sec. then restore normal received Press button2 once Power LED restore normal Hang up the call. When a call come or in communication or Dialing Press button2 for Power LED flash 2 times orange Send SOS report and into...
  • Page 6 V. PC SETUP AND SYSTEM INITIATION PC setup Procedure: 1.) Connect the standard RS232 cable to the DB9 port. 2.) Open the PC setup program. 3.) Select the correct COM port for communication. 4.) Power on the device. 5.) Click “OK” to Start the program Note that, if the connection fails, please check the cable connection is secured correctly.
  • Page 7 C. MAIN INTERFACE 1.[User detail]: If the SIM card is password protected, user can input the “SIM PIN” window to set password of SIM Card. Set UNIT ID and UNIT password of for the device. Set Access Point Name (APN), User Name, Password. The maximum length of the APN, User name and Password is 49 characters.
  • Page 8 Set the primary SMS Number of the server. The unit will send reports to the server if GPRS connection is failed. Setup the max. number of the SMS can be sent out from the unit every month. By default, it will be renewed by the first date of every month.
  • Page 9 Here is the section to set the 3 telephone numbers for speed dialing. Please refer to speed dialing button operation. 3.[Report]: Report setup can be configured in this section. To activate the function(s), please select “√” in checkbox and fill in data in the textbox. There are 2 modes for the GT-2000, first is the Normal mode, and second is the Power saving mode.
  • Page 10 Emergency request report: If the user does not set the keep alive, GT-2000 might lose the GPRS connection (if it is been cut by the Network). The system will not actively re-connect to server, it will wait for a new trigger (or report) and then start the connection / then send to the server.

  • Page 11: Appendix 1 Gt2000 Specifications

    It is distinguished by the tilt angle of the device. If the unit tilted more than the degree set here, GT-2000 will be in moving mode. Otherwise, it will be in stop mode. APPENDIX 1 GT2000 SPECIFICATIONS Physical Parameters Enclosure dimensions(mm) 94(L)*60(W)*28.5(H)
  • Page 12 IO Connection Four Button One Power button, 3 speed dialing buttons 1 volume adjust button Communication GPRS \SMS\RS232\ Environmental Operating Temperature -20°C to +55°C Storage Temperature -40°C to +85°C Accessories 1. Internal battery 2. PC setup cable Additional: 1. GPS indicator (bottom LED): LED is GREEN when the unit has acquired a valid GPS signal, and it will flash when the unit is searching GPS signal.
  • Page 13 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
