  • Page 1 User Manual...
  • Page 2 Thank you for buying the GoXtreme WiFi Control action camera. Before start using this product, please read this manual carefully to maximize its performance and extend the life of the product. Appearance and Buttons...
  • Page 3 Shutter button 8. Micro USB port Microphone 9. Mini HDMI port LCD display 10. Micro SD card slot Lens 11. External microphone Wi-Fi switch and status indicator 12. Battery cover push switch Power / Mode button 13. LED light Infrared signal reception light...
  • Page 4 LCD Display Illustration Turn on the GoXtreme WiFi Control, the LCD will display the following status and settings: 1. Camera mode 2. Video recording mode (default) 3. Wi-Fi icon (display when enabled) 4. TF card icon (display when loaded)
  • Page 5 6. Mute mode, displays when enabled, and disabled by default. 7. Counter, displays up to 999. 8. Timer, displays hours and minutes. 9. Battery icon: current battery level of the camera. Note: the above icons may vary according to the status of the GoXtreme WiFi Control.
  • Page 6 Working Mode Flow Chart After turn on the GoXtreme WiFi Control, you can press the Power/Mode button to switch the following modes in turn: Video mode (720P,30fps) Video preview mode (1080P default) Video mode (720P ,60fps) Camera mode (8MP) Camera mode (5MP)
  • Page 7 In camera mode, press the Shutter button to take photo. Use your GoXtreme WiFi Control When you use the GoXtreme WiFi Control for the first time, please: 1. Insert a micro SD or micro SDHC card, as shown in the following picture.
  • Page 8 2. Install the battery Please install the lithium battery correctly as shown in the following picture. Picture 1 Picture 2 Picture 3 Picture 4 Step 1. Push the battery cover switch to the lock position( ),and remove the battery cover. Step 2+3.
  • Page 9 3. Charging the battery. The DV uses a rechargeable lithium battery. When the DV is off, connect it to the PC via USB cable to charge the battery. During charging, the status indicator (blue) will light on, and the indicator off when charging completes. Note: When the DV is on, connecting it to the PC will not charge.
  • Page 10 3 seconds, LCD displays “OFF” and a beep can be heard from buzzer. Note: The DV will turn off automatically if it is idle for 5 minutes. Start to Use Default setting: After turn on the GoXtreme WiFi Control, the default setting is as below:...
  • Page 11 Video recording mode icon The DV is in video recording mode. Video resolution FHD: 1080p@30fps Recording time Stands for 0 hour and 00 minute. TF card icon Display when a TF card is inserted, otherwise no display. Battery level Battery is full...
  • Page 12 It displays only when Mute mode is activated. Wi-Fi icon Display when activated. The GoXtreme WiFi Control provides different shooting modes. Press the button repeatedly, the following mode will display in turn: HI stands for FHD (1920x1080,30 fps) video...
  • Page 13 HI stands for 8M (3264 x 2448) resolution Photo Lo stands for 5M (2592 x 1944) resolution Continuous shot The DV supports taking 3 photos continuously (only via App) Self-timer In self-timer mode , you can set 0s, 2s or 10s (only via App)
  • Page 14 Video To record a video, please check whether the DV is under Video mode. If the icon is not displayed on the screen, press the button repeatedly until it appears. Start recording: Press and release the button, the icon and [:] displayed in LCD will flash. At the same time the red indicator will flash too, meaning the recording is in process.
  • Page 15 Photo To take a photo, please check whether the DV is under Camera mode. If the icon is not displayed on the screen, press the button repeatedly until it appears. Press and release the button, a beep will be heard and the red indicator will flash, meaning a photo is taken.(If you take photos more than 999 copies, the LCD screen display only 999) 3.
  • Page 16 Wi-Fi is disabled by default When Wi-Fi is enabled, the Wi-Fi icon will display on LCD 4. Enable/disable Mute mode The buzzer is enabled by default. Under the Video or Photo mode, press and hold the Shutter button to disable the buzzer and indicator to enter Mute mode. Under Mute mode, the icon will display on the screen;...
  • Page 17 Buzzer is enabled by default When Mute mode is enabled, the Mute icon will display on LCD 5. Connecting to HDTV 5.1 Connect the DV to HDTV via HDMI cable (optional) If you need to transfer the image and audio to an HDTV for playback, insert the Com end of the HDMI cable to the DV, and the other end (output) to the HD input of the HDTV, as shown in the following figure:...
  • Page 18 Note: Before connecting or removing the HDMI cable, please stop video recording, playback and disconnect Wi-Fi first.
  • Page 19 5.2 When HDTV is connected, it enters Playback mode, the LCD displays as below: Icon name Description Under Playback mode currently. Playback mode There are 31 files and you are viewing the 19 one. File number Video icon The file is a video.
  • Page 20 In Playback mode, press the Power button to switch between photos and videos. When there are several photos or videos, press the Wi-Fi button to select the photo or video. When a video file is selected, press the Shutter button to play it, and press the Shutter button again to stop playing.
  • Page 21 6. Connecting to PC 6.1 Turn on the DV and connect it to the USB port of the PC via the attached USB cable. The DV will enter U-disk mode and the LCD will display as below after connection: Now you can view the photos or videos taken by DV on PC.
  • Page 22 Note: After the DV connecting to PC to enter U-disk mode, you will see two removable disks displayed in My computer of Windows, one is the TF card, storing all the photos taken and video recorded by users; the other one stores the system file information, including a file named SSID_PW.CFG, containing the AP ID of the DV and the password for AP login.
  • Page 23 Remote Controller Application Power off button Buttons Signal emission port Video button Photo button Instruction You can use the remote controller to record videos, take photos and shut down the DV. When using the remote controller, aim the signal emission port to the infrared signal reception light of the DV, and press the video button, photo button or power off button.
  • Page 24 Infrared signal reception light APP (support Android and iOS) 1. How to install an APP 1.1 Search for ”SYMAGIX” in Google Play (for Android OS),or scan the QR code printed on the gift box to find the APP and install it according to the instruction.
  • Page 25 2.2 Insert the TF card and turn on the DV, then press the Wi-Fi button to enable it. Now you can see the Wi-Fi icon on the LCD. 2.3 Enable Wi-Fi on Android phone or tablet and search for wireless AP signal “GoXtreme WiFi Control”, then connect it to DV, until the system displays “Connected successfully”.
  • Page 26 2.4 Click the icon in the App list of the Android phone or tablet to open it. Now you can preview the image sent by the DV on the phone or tablet and start some operating. The operation interface on terminal is shown in the following figure.
  • Page 27 3.2 Insert the TF card and turn on the DV, then press the Wi-Fi button to enable it. Now you can see the Wi-Fi icon on the LCD. 3.3 Enable Wi-Fi on iOS phone or tablet and search for wireless AP signal “GoXtreme WiFi Control”, then connect it to DV, until the system displays “Connected successfully”.
  • Page 28 1. DV battery icon 2. Video resolution 3. White balance 4. Setup (enter setup menu) 5. Enter Playback mode 6. Shutter button 7. Photo mode 8. Video mode...
  • Page 29 Note: 1. A TF card must be inserted if you need to take a photo, record a video or download files on the terminal. 2. The Wi-Fi indicator will remain on when the terminal is connected to DV.
  • Page 30 DECLARATION OF CONFORMITY easypix herebly declares that the product GoXtreme WiFi Control is in conformity to all the essential requirements of Directive 1999/5/EC. The declaration of conformity can be downloaded here: http://www.easypix.info/download/pdf/doc_goxtreme_wifi_control.pdf For technical help please visit our support area on www.easypix.eu.
