Hobie Wave Parts Manual page 2

tIllER CROss BARs
39521001 CLUb boLT (62")
39522001 TENdoN (62")
39524001 '07 EZ LoC (67")
eZ loC r a
udder ssemBly
39312000
Upper Bolt 8040391
Nut 8050331
Tiller Arm
39382011
Rudder Linkage
50313201
Tube Rivet
50313301
EZ LOC Housing 50313001
Detent Plunger 20492021
Retainer Clip 90880231
Bungee (3/16" x 10") RS316BLK
Lower Bolt 8040321
Washer 8080671
Nut 8050331
mAst
SERIAL NUMBER 0 THROUGH 1437
oLd ASSEMbLy NLA (SEE NEW STyLE
bELoW) CoNvERSioN REQUiRES
MAST STEP RETRofiT.
MAST bASE (HobiE14 STyLE)
10640011
SERIAL NUMBER 1438 AND NEwER
MAST ASSEMbLy (NEW STyLE)
38581041
LoWER MAST 38583141
NEW MAST bASE (CUP) 38641001
mAst stEp pARts
(*Conversion parts required to
retrofit new mast to old style boat):
*NEW STEP bALL 50212301
*NEW STEP PoST 38170001
*NEW MAST STEP CASTiNg 38171001
(flat top / threaded for post)
*RivET (4) 8011231
*STEP PiN -8020451
SHRoUd SE w/Hooks 38790001
bRidLE SE w/hooks 38822011
foRESTAy AdJUSTER
doWNHAUL / HALyARd CLEAT 10730000
SCREW 8030111
Pre-"EZ LOC" Rudder System
* = SUB ASSEMBLY PART / INCLUDED wITH CASTING
TiLLER ARM 38321111
Up-Lock 10480000
pin kit
50314001
50312301
LoWER CASTiNg
bLACK 50322001
RUddER PiN bUSHiNg
EZ LoC
UPPER 8062001
RUddER
LoWER 38360001
bLAdE
*RAKE AdJUSTMENT SCREW
20491000
8032001
*PLUNgER
50312201
*SPRiNg
10430000
*TENSioN SCREW
60450000
HALyARd
38651001
CoMPTiP
38582100
LUff TRACK
38584001
TANg
10690000
SHACKLE
10700000
WAVE ClUB WIREs
SHRoUd Club 39790001
foRESTAy 39810001
bRidLE Club 39822011
WAVE sE WIREs
foRESTAy 39810001
20830010
NUT 8051301
RigHTiNg LiNE RL012bLU - 15'
r a
udder ssemBly
*boLT
*WASHER
8040301
8080181
UPPER CASTiNg
*CAM bLACK
LEfT 50321001
RigHT 50341001
*CAM PLATE
*PiN
203520000
boLT
8040331
NUT
8050311
RUddER
bLAdE
20493000
WHiTE
fLoAT KiT 30115
bRACKET (1)
39640020
SCREW 8032011
MAST HEAd
10602111
MAiN
SAiL 3899XXXX
SHRoUd AdJUSTER
(CLUb) 20830010
tIllER COnnECtOR kIts And pARts
1957 KiT - '07 TiLLER CoNNECToR
1956 KiT - CLUb TiLLER CoNNECToR
(REPLACES TENdoN STyLE WiTH CLUb boLT STyLE)
1954 KiT - CLUb TiLLER CoNNECToR / UPgRAdE foR EARLy boATS
WiTH oRigiNAL CURvEd TENdoN CoNNECToRS:
iNCLUdES TiLLER CRoSS bAR ANd ALL TiLLER CoNNECToR fiTTiNgS
'07 tIllER COnnECtOR (1957)
ClUB tIllER COnnECtOR (1954 / 1956)
TiLLER CoNNECToR SCREW 40530021
TiLLER ARM
SWivEL
ENd CAP
40650001
tEndOn tIllER COnnECtOR
bATTEN #5 36"
bATTEN #4 50"
bATTEN #3 66 7/8"
bATTEN #2 77 7/8"
bATTEN #1 82 3/8"
38016001 HobiE WAvE bATTEN SET
(foR iNdividUAL bATTENS SEE UNivERSAL bATTENS oN PAgE 14)
Wave Rivet guide
( ) Quantity needed to fasten part
mast Rudder Assembly
Head 8010131 (2) Upper Casting
Halyard Hook 8010181 (2) (Underside)
8011291 (2) Tiller End Cap
Tang 8010181 (6)
8011291 (6) sail
Halyard Cleat 8010121 (2) Headboard
base 8010131 (3) Tack/Clew plate
Pocket Protector
Rear Crossbar (Requires setting machine-not available as
Pad Eye 8010181 )2) hand tool)
Front Crossbar
Mast Step 8011231 (4)
"S" HooK 38900031
SHACKLE 11220000
UPPER
bLoCK
38900061
RM516bLU X 35'
HOBIE WAVE
ENd CAP - WiTH PiN 37561203
ENd CAP - THRoUgH HoLE 37561200
CLiP 40590001
SCREW 8031151
RivET 8010261
SHoCK CoRd (10") RS316bLK
iNSERT bEARiNg 40680001
TiLLER ARM iNSERT 40660001
boLT 8040171
WASHER 8080691
ENdCAP 37561001
fibER TENdoN 37561011
fibER-TENdoN SCREW 8030071
QUiCK PiN 8020461
LANyAd 37660091
8010131 (2)
8011231 (1)
8010131 (2)
8010020 (16)
8010020 (6)
8010020 (4)
LoWER
bLoCK 38900071
45
