Hobie Wave Parts Manual

HOBIE WAVE
REPLACEMENT HULL - LEfT 39010001
REPLACEMENT HULL - RigHT 39020001
ClAssIC / sE WAVE
EyESTRAP
38120011
SCREW
8030331
ALUMiNUM CASTiNg PiNTLES
UPPER PiNTLE 38101301
LoWER PiNTLE 38101401
EZ LoC RUddER PiNTLES
UPPER PiNTLE 90880211
LoWER PiNTLE 90880221
LoNg LoCK SCREW 8030411
KEEPER WiRE /W PiN 38490011
ClUB WAVE
( CLUb WAvE vERSioN–iTEMS LiSTEd bELoW oNLy if diffERENT fRoM STANdARd WAvE ModEL. )
44 HOBIE WAVE
WAVE VERsIOn nOtEs:
stAndARd WAVE / ClAssIC OR "sE" - (CAR ToPPAbLE) oNE PiECE TRAMPoLiNE, SHRoUdS ANd bRidLES CoNNECT WiTH HooKS
ClUB WAVE -THREE PiECE TRAMPoLiNE. SHRoUdS ANd bRidLES CoNNECT WiTH CLEviS PiNS
CLUB items listed only if different from standard SE wave model.
SEAT PAd
LT bLUE 38010061
PoRT CovER (UNdER SEAT PAd)
38370001
SCREW (NEWER ModELS ANd RETRofiTS)
8031950
CHAiN PLATE 39100011 (PAiR)
SCREW 8030331
iNSERT CAP 38120031
oLdER -
TRAMPoLiNE ANCHoR HooK 38760031
NEWER-
(boATS WiTH TRACKS)
TRAMP TENSioN SLidE 38760071
SToPPER / foAM 8003255 (fT)
dRAiN PLUg W/gASKET
91281000
AfTER S/N 1973 USE 10091000
TRAMP TRACK
39341011
CHAiN PLATE
39100011
iNSPECTioN PoRT 5"
41370001
'97–nEWER
(sn 1438-ABOVE)
foRWARd CRoSSbAR 38131041
MAST STEP CASTiNg 38171001
PoST (THREAdEd) 38170001
bALL 50212301
bASE STEP PiN 8020451
'96–OldER
MAST STEP CASTiNg 10170011
MAST STEP LiNK KiT 21380001
TRAMP TENSioN HooK
38760061
RiNg 61290011
TRAMP TENSioN
WiRE 38970051
TRAMP TUbE (4 PER
SidE) 38760021
REAR CRoSSbAR 38191031
CRoSS bAR SToP PLATE
38132001
SE LACE Rod 49" 38881011
SE vELCRo LACE STRAP
(4 PER boAT) 38970061
ACCESSORIES
boW SPREAdER 38999021
boW SPREAdER TANg 38120041
sEAt BACkREst kIt 38040011
bACKREST iNSTALLATioN QUiCK PiN 8020181
bACKREST PLUg, foRWARd 38660011
bACKREST PLUg, AfT 38660031
mAIn tRAVElER kIt (ClUB) 39250000
bLACK foRWARd
ENd CAP 39130021
TURNiNg bLoCK H224
EyE STRAP KiT 2072
- EyE STRAP 10076
- SCREW SS010320515
- NUT 8051301
ClAssIC tRAmpOlInE
3897XXXX
(XXXX = Color / See parts list for
available options)
TURNiNg bLoCK H225
bLACK REAR
ENd CAP 38190021
ENd CAP 38950011
ClUB tRAmpOlInE
3997XXXX
(XXXX = Color / See parts list for
available options)
TRAMP LACE LiNE RH014WHT
CENTER - 21'
AfT - 11' (2)
