Leviton Melange Pro Features

Memory Lighting Control Console
MOUSE PRINTER
LOAD CANCEL TOGGLE
SUBMASTERS
10
9
8
7
6
5
4
3
2
1
0
1 2 3 4 5 6 7 8
10
9
8
7
6
5
4
3
2
1
0
13 14 15 16 17 18 19 20 21
Because of its flexibility, ease of use and automation
features, the reasonably priced Melange Pro consoles fill
a multitude of needs serving theatrical dealers, rental
A/V and contractor markets. With MIDI, SMPTE, RTC,
external macros and 2 autofaders that nest cues
three deep, churches, theme parks, high schools, and
universities will find the Melange Pro consistently
performs as a solid, accommodating lighting tool.
The Melange Pro control consoles provide 128 channels
to control as many as 512 dimmer channels, with
multiple proportional softpatch tables. Along with 400
cues, 99 level sensitive chase effects, each up to 250
steps, and 99 submaster memory pages, this console
gives the user hands-on control of multiple looks and
cued memory. Other control functions include two
autofaders to advance preprogrammed cues, with
programmable fade rates from .1 to 99.59.9 minutes,
and two manual faders for real time, take-control
operation. The consoles also feature an internal 10 year
EEPROM memory protection to ensure programs are
Leviton Mfg. Co., Inc. P. O. Box 2210, Tualatin, OR 97062 Phone: (503) 404-5500 • Fax: (503) 404-5594
MIDI CONNECTORS
EXTERNAL REMOTE FOCUS
THRU OUT IN
VGA INPUTS SERIAL I/O AUDIO IN
MELANGE PRO - REAR PANEL
29.090
SOLO
10
9
8
7
6
5
MEMORY LIGHTING CONTROLLER
4
3
2
1
0
A B C
9 10 11 12 CANCEL CANCEL CANCEL SELECT
10 10 0 10 0
BACK
9 9 1 9 1
8 8 2 8 2
7 7 3 7 3
6 6 4 6 4
5 5 5 5 5
HOLD
4 4 6 4 6
3 3 7 3 7
2 2 8 2 8
1 1 9 1 9
0 0 10 0 10
22 23 24 LOAD LOAD GO LOAD
Copyright © 1995, 2001, 2002, Leviton Mfg. Co., Inc.
PUSH
_
O
MICROPLEX OUT DMX512 IN DMX512 OUT
Melange Pro
D
CANCEL F1 F2 F3 F4
7 8 9 FULL MACRO
FAST
4 5 6 THRU RECORD
SLOW
1 2 3 AND EDIT
GO CLEAR 0 AT / . ENTER HELP
retained even when power is off.
The Melange Pro consoles support VGA monitors
and provide display of channel level information,
programming screens, cue attributes, cue sheets, patch
table, console configuration, memory allocation, and
help information. With the onboard 3.5 inch disk drive,
all memory and console configurations can be saved
and edited on a PC by any text-based editor.
Dimensional Data
Width
Depth
Height
Shipping Weight
Melange
Pro
3.751
BLACKOUT
15.000
10
9
8
7
6
5
4
3
2
1
0
GRAND
MASTER
– in.[cm]/lbs.[kg]
29 [73.66]
15 [38.1]
4 [10.16]
18.5 [8.4]
