- Page 1 Remote Control Panel Installation & Operation Guide 400CP...
-
Page 2: Table Of Contents
Table of Contents INTRODUCTION ......................... 3 IMPORTANT......................... 3 WIRING..........................3 PROGRAMMING........................5 OPERATION ........................12... -
Page 3: Introduction
Introduction The Leviton 400CP represents a key part of a state of the art, total lighting control system. Combined with Leviton dimmers and optionally, a Leviton memory control console, a totally integrated system is achieved. The 400CP can automatically take control of up to 512 dimmer channels. Control is automatically passed between400CP’s and the memory control console as desired. - Page 4 MOUNTING The 400CP will mount in any standard double-gang electrical box with the 4 screws provided. See below paragraph on system turn-on before final mounting of panels. SYSTEM TURN-ON It is very important that the system operation be verified one panel at a time or else an improper connection at one panel would cause the entire system to not operate properly and may be difficult...
-
Page 5: Programming
Factory Default Setting: The 400CP is programmed at the factory for zone 1-4 to be set for channel 1-4 respectively. The fade rate ant other parameters are also set to factory defaults. This may be acceptable for initial testing. - Page 6 The maximum number of dimmers may be set as follows: 1. Make sure that the 400CP is in the program select mode as discussed. 2. Press the zone 1 increase button and the BUSY led will quit flashing.
- Page 7 LEDs of the dimmers may be observed to verify channel selection. To program each zone: 1. Make sure that the 400CP is in the program select mode as discussed. The BUSY LED should be flashing. 2. Press the zone 2 increase button to select "dimmer assignment mode" and the BUSY LED will stop flashing.
- Page 8 5 seconds is desired for each zone then this step may be ignored. To program zone fade time: 1. Make sure that the 400CP is in the program select mode as discussed. 2. Press the zone 3 increase button to enter "fade time mode" and the BUSY LED will stop flashing.
- Page 9 Master/Slave Mode 400CP panels may be slaved to one another. Several panels may act as slaves to a master panel which contains the programming. The slaves will mimic the master LED’s and will operate the scenes and fade times of the master. This is ideal for installations with several panels in one room.
- Page 10 To set Network ID number (units without dipswitch): 1. Make sure that the 400CP is in the program mode as discussed. 2. Press the zone 1,2,3,4 increase buttons at the same time and the BUSY LED will stop flashing...
- Page 11 ID number codes / dipswitch settings ID number 12345678 ID number 12345678 ID number 12345678 00000000 10000000 01000000 11000000 00100000 10100000 01100000 11100000 00010000 10010000 01010000 11010000 00110000 10110000 01110000 11110000 00001000 10001000 01001000 11001000 00101000 10101000 01101000 11101000 00011000 10011000 01011000 11011000...
-
Page 12: Operation
LIMITED 2 YEAR WARRANTY AND EXCLUSIONS Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by Leviton is free of defects in materials and workmanship under normal and proper use for two years from the purchase date. Leviton’s only obligation is to correct such defects by repair or replacement, at its option.
