The Polk Audio SurroundBar
Specifications
Bar Components
Subwoofer
Lower/Upper
-3dB Limit
Peak System Power
Inputs
Dimensions
Backup Remote
Control
Included Cables &
Accessories
Finish: satin black bar & subwoofer
MSRP: $849
Technical Brief
5- 2 1/2" midwoofers
3- 1/2" silk dome tweeters
Wireless 8" downfiring long throw woofer automatically pairs with
bar
45 Hz - 20 kHz
510W - 45 x 8 channels and 150W subwoofer
Two optical, two 1/8" analog
bar: 3 3/4" h x 44 5/8" w x 2 1/4" d
sub: 13 1/2" h x 12" w x 13 1/2" d
on/off, bar volume, subwoofer volume,
mute, source selection, learn
-6' digital (Optical) cable
-1/8" to 1/8" analog cable
-1/8" female to dual RCA male adapter
- two removable rubber feet adjustable along the bar length
®
9000 Instant Home Theater™
Advertisement
Related Manuals for Polk Audio SurroundBar 9000
Summary of Contents for Polk Audio SurroundBar 9000
- Page 1 Technical Brief ® The Polk Audio SurroundBar 9000 Instant Home Theater™ Specifications Bar Components 5- 2 1/2" midwoofers 3- 1/2" silk dome tweeters Subwoofer Wireless 8” downfiring long throw woofer automatically pairs with Lower/Upper 45 Hz - 20 kHz -3dB Limit...
-
Page 2: System Description
Design Goals The foremost design goal for our best Instant Home Theater system was to create dynamic range, system clarity, and bass response of equivalent component home theater system with the ease of hookup and use consumers expect of a powered soundbar system. - Page 3 Technologies 8 Channel Amplifier Each of the 5 mid-bass drivers and 3 tweeters is driven by a dedicated amplifier channel. High and low pass filters are handled electronically with no passive componentry in the signal path. This reduces phase shift and lowers distortion inherent in all passive crossover networks.
- Page 4 only the center driver plays center channel program material through the upper midrange all the way up to its crossover point with the center tweeter (80Hz - 4kHz). Meanwhile, the outer tweeters are also employed as “super tweeters” (6kHz – 20kHz) for center channel material in addition to serving their primary duties in the reproduction of Front (FL/FR) and Surround (SL/SR) channels.
- Page 5 sources all around you. As far as you are concerned there really are sounds all around you. This technology requires no reflecting surfaces or special speaker placement. It works well in virtually any room of any size or shape and delivers a surround sound experience for almost all listener locations (see Figure 2).
