PRODUCT GUIDE
MODEL 466440509
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
Please call
Estimated assembly time: 45 minutes
®
®
Printed in China
See rating label on grill for serial number.
1-800-241-7548.
Assembly instructions © 2008
10/16/08 • 80018768
.
TM REVISION 00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 466440509 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Char-Broil 466440509

Summary of Contents for Char-Broil 466440509

  • Page 1 PRODUCT GUIDE MODEL 466440509 IMPORTANT: Fill out the product record information below. Serial Number See rating label on grill for serial number. Date Purchased For support and to register your grill, please visit us at www.charbroil.com If you have questions or need assistance during assembly, 1-800-241-7548.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DANGER For Your Safety ........2-3 If you smell gas: Use and Care .
  • Page 3 WARNING CAUTION CALIFORNIA PROPOSITION 65 Using pots larger than 6 quarts in capacity could 1. Combustion by-products produced when using exceed weight limit of the this product contain chemicals known to the State of side burner shelf, California to cause cancer, birth defects, and other resulting in failure reproductive harm.

  • Page 4: Use And Care

    LP Cylinder USE AND CARE •The LP cylinder used with your grill must meet the following requirements: •Use LP cylinders only with these required measurements: 12" DANGER (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) capacity maximum. •...

  • Page 5: For Your Safety

    LP Cylinder Exchange Connecting Regulator to the LP Cylinder 1.LP cylinder must be properly secured onto grill. (Refer to •Many retailers that sell grills offer you the option of replacing your empty LP cylinder through an exchange service. Use only assembly section.) those reputable exchange companies that inspect, precision fill, 2.Turn all control knobs to the OFF position.
  • Page 6 Leak Testing Valves, Hose and Regulator 1.Turn all grill control knobs to OFF. 2.Be sure regulator is tightly connected to LP cylinder. 3.Completely open LP cylinder valve by turning hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
  • Page 7 Safety Tips WARNING Before opening LP cylinder valve, check the coupling nut for tightness. When grill is not in use, turn off all control knobs and LP For Safe Use of Your Grill and to Avoid Serious cylinder valve. Never move grill while in operation or still hot. Injury: Use long-handled barbecue utensils and oven mitts to avoid •...
  • Page 8 Burner Flame Check WARNING •Remove cooking grates and flame tamers. Light burners, rotate knobs from HIGH to LOW. You should see a smaller flame in Turn controls and gas source or tank OFF when not LOW position than seen on HIGH. Perform burner flame check in use.

  • Page 9: Spider Alert

    Cleaning the Burner Assembly CAUTION Follow these instructions to clean and/or replace parts of burner assembly or if you have trouble igniting grill. 1. Turn gas off at control knobs and LP cylinder. SPIDER ALERT! 2. Remove cooking grates and flame tamers. 3.

  • Page 10: Grilling Guide

    Temperature GRILLING GUIDE – Getting Started The temperature gauge in the hood of your new grill measures First Time Use air temperature. The air temperature inside your grill will never be as hot as the temperature at the cooking surface. Read your Assembly Manual and ensure the grill is put together properly.
  • Page 11 Rotisserie Cooking GRILLING GUIDE – Grilling 101 Rotisserie cooking is best for 'round' meat, such as large roasts, whole poultry, and pork. It generally requires an accessory motor Outdoor grilling is really quite simple. You'll succeed with and spit rod that allows the meat to be turned at a constant burgers, dogs, or steaks usually on your very first try.
  • Page 12 Wood Chips GRILLING GUIDE – Tips & Tricks For extra smoke flavor when grilling, try adding wood chips. Cooking on your new grill is a hands-on experience, and it is Soak the chips in water for approximately 30 minutes before recommended to remain outside with your grill while cooking.
  • Page 13 Cooking surfaces: If a bristle brush is used to clean any of the GRILLING GUIDE – Cleaning Your Grill grill cooking surfaces, ensure no loose bristles remain on cooking Why Clean? surfaces prior to grilling. It is not recommended to clean cooking surfaces while grill is hot.

  • Page 14: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 15: Parts List

    PARTS LIST Key Qty Description Key Qty Description 1 FIREBOX 1 GREASE CUP 4 TUBE BURNER 1 CLIP, F/ GREASE CUP 1 ELECTRODE, MAIN BURNER 1 TANK EXCLUSION 3 CARRY OVER TUBE MM 2 LEG EXTENDER 1 CONTROL PANEL, MAIN 1 WING SCREW F/ TANK 1 ELECTRONIC MODULE, W/BUTTON OO 2 LID BUMPER, ROUND...

  • Page 16: Parts Diagram

    PARTS DIAGRAM...

  • Page 17: Assembly

    ASSEMBLY Place legs as shown . Left leg assembly has large holes on ends of legs. Hook tank exclusion wireinto right and left leg assemblies Right Leg Assembly Tank Exclusion Wire Left Leg Assembly Right Leg Assembly Place bottom shelf with cut out hole for LP tank next to legs with axle holes. Attach to right and left leg assemblies with 1/4 -20x1-1/2"...
  • Page 18 Attach front panel to cart with #8-32x3/8" sheet metal screws. ASSEMBLY Front Panel Qty: 6 #8-32X3/8” Sheet Metal Screw Turn assembly upside down. Insert axle rod into wheel, Axle Spacer, legs and other Axle Spacer and wheel. Attach with (1) 8mm flat washer and hitch pin.
  • Page 19 Stand cart upright. This step requires two people to lift and position grill head onto cart. Carefully lower the grill head onto the cart. Make sure the regulator hose is hanging outside the cart. Attach with 1/4 -20x1/2" machine screws. "...
  • Page 20 Hook side wall of shelf over support brackets on side of firebox (A). Inside firebox insert 7x15 fiber washers and 1/4 -20x1/2" machine screws as shown (B). " Attach shelf with flange nuts on each side. (C). Bracket Right Side Shelf Qty: 4 Qty: 4 1/4 -20x1/2"...
  • Page 21 Hook side wall of sideburner shelf over support brackets on side of firebox (A). Inside firebox insert 7x15 fiber washers and 1/4 -20x1/2" machine screws as shown (B). " Attach sideburner shelf with flange nuts on each side. (C). Sideburner Shelf Qty: 4 Qty: 4 1/4 -20x1/2"...
  • Page 22 Attach sideburner bezel and valve with #8-32x3/8" machine screws (A). Place sideburner into shelf. Make sure valve is inside sideburner tube. Attach sideburner with wing nut (B). Hook burner clip to sideburner tube and around manifold. Attach sideburner ignitor wire (C) Press sideburner control knob onto valve stem (D).
  • Page 23 Place heat tents over burners by inserting tabs into slots in front of firebox. Opposite ends of heat tents rest on pins in back of firebox. Place cooking grates onto grate rests. Insert ends of Swing Away pivot wire into holes in sides of grill lid. Insert ends of Swing Away leg wire into holes in sides of firebox. NOTE: Pivot and leg wires, running side-to-side, should be under wires running front-to-back.
  • Page 24 Hang grease cup clip from bottom of firebox and place grease cup into grease clip. Grease Cup Clip Grease Cup CAUTION Failure to install grease cup clip and cup will cause hot grease to drip from bottom of grill with risk of fire or property damage. LP tank is sold separately.

  • Page 25: Troubleshooting

    EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from •Damaged hose. •Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.
  • Page 26 Troubleshooting (continued) Problem Possible Cause Prevention/Solution ELECTRONIC IGNITION: Burner(s) will not light using ignitor. •No spark, no ignition noise. • See Section I of Electronic Ignition System. (See Electronic Ignition Troubleshooting also) •No spark, some ignition noise. • See Section II of Electronic Ignition System. •Sparks, but not at electrode or at full •...

  • Page 27: Troubleshooting

    Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause Check Procedure Prevention/Solution SECTION I No sparks appear at •Battery not installed •Check battery orientation. •Install battery (make sure that “+” and “–” any electrodes when properly. connectors are oriented correctly, with “+” end up and “–”...
  • Page 28 NOTES...
  • Page 29 NOTES...
  • Page 30 NOTES...

  • Page 31: Registration Card

    REGTEMP REV00...
