Operation 8035C
Time
of day
Day
Time
Slot
Touch Screen
Current
Room
Temperature
Target
Temperature
Thermostat
Mode
Fan
Switch
Statement of use: The GPMG8035C can be used with
most 24 volt gas, oil or electric heating and air
conditioning systems, single-stage heat pumps or gas
millivolt heating systems. It cannot be used with 120
volt heating systems or multistage heat pumps.

Basic Screens

The MODE SWITCH of the
8035C must be in the HEAT or
the COOL position to access all
control functions. The 8035C
Thermostat has 3 basic screens.
The HOME screen is displayed
when unit is operating your
system.
Touching the
return you to this screen.

HOME screen

Mode
Switch
Current Room
will always
Temperature
Chirp indicator
Using a TOUCH SCREEN
Please take a moment to try out
your touch screen itself.
Menu
To select a function on the
button
touch screen, place your finger
on the main temp display and
give a short firm push. Try a "tap"
of the finger or stylus. Your input
Program
button
must last long enough for the
system to determine it is not an
accidental 'bump'.
Using the stylus is more
comfortable for some users.
Again allow the system enough
time to recognize your inputs.
Reset
When you are comfortable with
button
touch inputs, proceed.
Time of day
Touch here
to change
from 12 to 24hr
clock display.
Day
Time
Slot
Target
Temperature
Thermostat
Mode
1
PG
2
PG
