- Page 1 GS-1124B USER’S GUIDE Unmanagement 24-port Gigabit Ethernet Switch Edition 1, 1/2009 www.zyxel.com Copyright 2009 ZyXEL Communications Corporation...
-
Page 2: Front And Rear Panels
Front and Rear Panels Power (AC INPUT) Ethernet Port LEDs PWR LED Ethernet Ports 1~24 The LED definitions are described in the following table. COLOR STATUS DESCRIPTION Green The switch is on and receiving power. The switch is not receiving power. LINK/ Green The port is connected to an Ethernet network. -
Page 3: Package Contents
Introduction The switch is a multi-port switch that can be used to build high- performance switched workgroup networks. The switch is a store-and- forward device that offers low latency for high-speed networking. The switch is designed for workgroups, departments or backbone computing environments for SME (small, medium enterprise) businesses. -
Page 4: Standalone Workgroup
• Four self-adhesive rubber feet and screws • Rack mount brackets • Warranty card Applications This section provides two network topology examples in which the switch is used. Standalone Workgroup In this application, the switch is an ideal solution for small networks where rapid growth can be expected in the near future. - Page 5 Bridging With its large address table and high performance, the switch is an ideal solution for department networks to connect to the corporate backbone or for connecting network segments. The following figure depicts a typical segment bridge application of the switch in an enterprise environment.
-
Page 6: Specifications
Specifications Product specifications are accurate at the time of writing. Feature Specification Device Dimensions (mm) 441 (Wide) x 130 (Deep) x 44 (High) 19’’ rack mountable Device Weight 1.737 kg Interface 24 1000 Base-T RJ-45 Ethernet ports: Auto-MDIX 10/100/1000Mbps auto-sensing Compliant with IEEE 802.3/3u Back pressure flow control for half duplex Power Supply... -
Page 7: Safety Warnings
Feature Specification Layer 2 features Switching fabric: 48 Gbps Memory buffer: 500 KB Support frame size: 1522 bytes MAC table: Up to 8000 MAC addresses Jumbo frame size support: Up to 9 KB Standard IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000Base-T IEEE 802.3x Flow Control and Back-pressure IEEE 802.1p Class of Service... -
Page 8: Legal Information
• Do NOT remove the plug and plug into a wall outlet by itself; always attach the plug to the power supply first before you insert it into the wall. • Do not use the device outside, and make sure all the connections are indoors. There is a remote risk of elec- tric shock from lightning. -
Page 9: Zyxel Limited Warranty
Help us help you. E-mail all User Guide-related comments, questions or suggestions for improvement to techwriters@zyxel.com.tw or send regular mail to The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. Thank you. -
Page 10: Customer Support
Czech Republic • E-mail: info@cz.zyxel.com • Telephone: +420-241-091-350 • Fax: +420-241-091-359 • Web: www.zyxel.cz • Regular Mail: ZyXEL Communications, Czech s.r.o., Modranska 621, 143 01 Praha 4 - Modrany, Ceska Republika Denmark • Support E-mail: support@zyxel.dk • Sales E-mail: sales@zyxel.dk •... - Page 11 • Support E-mail: support@zyxel.fi • Sales E-mail: sales@zyxel.fi • Telephone: +358-9-4780-8411 • Fax: +358-9-4780-8448 • Web: www.zyxel.fi • Regular Mail: ZyXEL Communications Oy, Malminkaari 10, 00700 Helsinki, Finland France • E-mail: info@zyxel.fr • Telephone: +33-4-72-52-97-97 • Fax: +33-4-72-52-19-20 • Web: www.zyxel.fr •...
- Page 12 • Sales E-mail: sales@zyxel.com • Sales Telephone: +1-714-632-0882 • Fax: +1-714-632-0858 • Web: www.zyxel.com • Regular Mail: ZyXEL Communications Inc., 1130 N. Miller St., Anaheim, CA 92806-2001, U.S.A. Norway • Support E-mail: support@zyxel.no • Sales E-mail: sales@zyxel.no • Telephone: +47-22-80-61-80 •...
- Page 13 • Telephone: +44-1344-303044, 0845 122 0301 (UK only) • Fax: +44-1344-303034 • Web: www.zyxel.co.uk • Regular Mail: ZyXEL Communications UK Ltd., 11 The Courtyard, Eastern Road, Bracknell, Berkshire RG12 2XB, United Kingdom (UK) How to View a Product’s Certification(s) 1 Go to www.zyxel.com.
