HOW TO CLEAN & ASSEMBLE YOUR SNOW CONE MAKER
CAUTION: The stainless steel BLADE is very sharp. Never
attempt to touch the tip of the BLADE when operating,
assembling, disassembling, or cleaning.
1. Make sure the unit is unplugged.
2. R emove COVER by pressing the COVER RELEASE BUTTON
located on the back side of the unit. Lift COVER to remove.
3. T o remove DASHER, turn the DASHER counter-clockwise
until it is completely unscrewed from the UPPER HOUSING.
Lift DASHER to remove.
4. R emove UPPER HOUSING by twisting the UPPER HOUSING in
a counter-clockwise motion, until it unlocks from the LOWER
HOUSING. (There are two sets of arrows on the backside of
the unit that mark where to align the UPPER HOUSING with
-E4-
the LOWER HOUSING.) Do not attempt to remove the UPPER
HOUSING until the DASHER has been removed first.
5. W ipe down all parts and surfaces with a clean damp cloth, being
careful to avoid direct contact with the BLADE. The COVER/LID,
DASHER, and UPPER HOUSING may also be cleaned in the
dishwasher. Do NOT place the LOWER HOUSING in the dishwasher.
CAUTION: Do not immerse assembled unit in water.
TO REASSEMBLE: Reverse the above procedure, making sure that the
UPPER HOUSING is locked and aligned with the LOWER HOUSING before
inserting the DASHER. Make sure to screw DASHER tightly back into place.
TO ATTACH COVER: Align the tab underneath the COVER with the tab
slot on the front side of the UPPER HOUSING. Carefully lower the COVER
onto the UPPER HOUSING, making sure that the tab is still aligned with
the tab slot. (NOTE: you will not be able to see the tab inserted into the
tab slot as you lower the COVER, but try to keep the COVER aligned in
this same position as you lower it onto the UPPER HOUSING.)
TAB SLOT
TAB
-E5-
