4

Connecting the Adapter

Connecting a Single 3D Video Source
Power off all devices prior to connecting the Adapter.
If the device was in use prior to adding the Adapter, use the same
TV input if possible.
On an 833 series TV, the input must be named
Step 1.
Step 2.
Step 3.
If your 3D glasses require an emitter, connect it to the Adapter.
Step 4. Power on the TV.
Step 5.
Step 6. Power on the source device.
Step 7.
Adapter
Connecting Multiple 3D Video Sources
Connect devices with checkerboard output directly to the TV.
Enable checkerboard output from the devices if needed.
If using a newer A/V receiver, you may be able to connect devices
to the A/V receiver as shown below. The A/V receiver must support
HDMI 1.4 and 3D video capabilities.
HDMI
cables
A/V
Source
receiver
devices
Please check www.mitsubishi-tv.com for updates on 3D signals and safety.
AC power adapter
(provided)
DIN cable
(provided)
Emitter
3D GLASSES
EMITTER OUT
HDMI cable
(provided)
HDMI cable
HDMI
cables
Adapter
Game.
3D
GLASSES
EMITTER
HDMI
input
TV
Source device
TV
