15, 19, 22, 26, 32-inch class
LCD TV/DVD COMBINATION
15DV703R
19DV703R
19DV704R
22DV703R
OWNER'S MANUAL
© 2010 Toshiba Corporation
Before operating the unit, please read this manual thoroughly.
22DV704R
26DV703R
32DV703R
Owner's Record
The model and serial numbers are on the
back of your TV/DVD.
Record these numbers in the spaces
below. Refer to these numbers whenever
you communicate with your Toshiba
dealer about this TV/DVD.
Model number: _________________
Serial number: _________________
