Technical Specifications

Technical Specifications
Model FD8371EV
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 256 MB
RAM 512 MB
Camera Features
Image Sensor 1/2.8" Progressive CMOS
Maximum Resolution 2048x1536
Lens Type Vari-focal, remote focus
Focal Length f = 3 ~ 10mm
Aperture F1.3 ~ F2.5
Auto-iris P-iris / DC-iris (Reserved)
Field of View 32° ~ 99° (Horizontal)
24° ~ 72° (Vertical)
40° ~ 128° (Diagonal)
Shutter Time 1/5 sec. to 1/8000 sec.
Physical Adjustment of Pan: 348°, Tilt: 65°, Rotation: 350°
Camera Angel
WDR Technology WDR Enhanced
Day/Night Removable IR-cut filter for day & night function
Smart IR Technology to Avoid Overexposure
Minimum Illumination 0.33 Lux @ F1.3, 50 IRE (Color @1/30 sec)
0.05 Lux @ F1.3, 50 IRE (Color@1/5 sec)
0.001 Lux @ F1.3 50 IRE (B/W)
Pan/tilt/zoom ePTZ:
Functionalities 48x digital zoom (4x on IE plug-in,12x built in)
IR Illuminators Built-in IR illuminators, effective up to 20 meters
IR LED*4, with Smart IR Technology
On-board Storage MicroSD/SDHC/SDXC card slot
Video
Compression H.264, MJPEG & MPEG-4
Maximum Frame Rate H.264:
30 fps at 2048x1536
60 fps at 1920x1080
MPEG-4:
30 fps at 2048x1536
50 fps at 1920x1080
MJPEG:
30 fps at 2048x1536
60 fps at 1920x1080
Maximum Streams 4 simultaneous streams
S/N Ratio 58 dB
Dynamic Range 59 db
Video Streaming Adjustable resolution, quality and bitrate
Image Settings Adjustable image size, quality and bit rate
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast, saturation,
sharpness, white balance, exposure control, gain,
backlight compensation, privacy masks,
Scheduled profile settings, 3D Noise Reduction
Audio
Audio Capability Two-way Audio (full duplex)
Compression GSM-AMR, AAC, G.711
Interface External microphone input and output
Network
Users Live viewing for up to 10 clients
Protocols IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP,
DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
10Base-T/100 BaseTX Ethernet (RJ-45)
Interface
ONVIF Supported, specification available at www.onvif.org
Compatible Accessories
Mounting Kits
AM-214
L shape bracket
Distributed by:
Intelligent Video
Video Motion Detection
Alarm and Event
Alarm Triggers
Alarm Events
General
Smart Focus System
Connectors
LED Indicator
Power Input
Power Consumption
Dimensions
Weight
Casing
Safety Certifications
Operating Temperature
Warranty
System Requirements
Operating System
Web Browser
Other Players
Included Accessories
CD
Others
Dimensions
PoE Kits
AM-518 POE-IJ-1748NDN
Outdoor Dome Adaptor PoE injector, 802.3af compliant
All speci cations are subject to change without notice. Copyright © 2013 VIVOTEK INC. All rights reserved.
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T: +886-2-82455282| F: +886-2-82455532| E: sales@vivotek.com
VIVOTEK USA, INC.
2050 Ringwood Avenue, San Jose, CA 95131
|T: 408-773-8686| F: 408-773-8298| E: salesusa@vivotek.com
Triple-window video motion detection
Video motion detection, manual trigger, digital input,
periodical trigger, system boot, recording notification,
camera tampering detection ,audio detection
Event notification using digital output, HTTP, SMTP,
FTP and NAS server
File upload via HTTP, SMTP, FTP and NAS server
Remote focal & focus control
Focus assist button and OSD
RJ-45 cable connector for Network/PoE connection
Audio input
Audio output
AC 24V power input/DC 12V power input
Digital input*1
Digital output*1
Analog video output
System power and status indicator
24V AC
12V DC
IEEE 802.3af PoE Class 3
Max. 28W (DC 12V)
Max. 34W (AC 24V)
Max. 12.95W (PoE)
Ø: 173 mm x 115 mm
Net: 1,240g
Weather-proof IP66-rated housing
Vandal-proof IK10-rated housing
CE, LVD, FCC Class A, VCCI, C-Tick, UL, KCC
Starting Temperature: -40°C ~ 50°C (-40°F ~ 122°F)
Working Temperature: -50°C ~ 50°C (-58°F ~ 122°F)
24 months
Microsoft Windows 7/Vista/XP/2000
Mozilla Firefox 7~10 (Streaming only)
Internet Explorer 7.x or 8.x
VLC: 1.1.11 or above
Quicktime: 7 or above
User's manual, quick installation guide, Installation
Wizard 2, ST7501 32-channel recording software
Quick installation guide, warranty card, alignment
sticker, mounting plate, L-type hex key wrench,
desiccant bag, DC connector, screws, hex nut,
double-sided Tape, AV cable, waterproof connector,
bushing, software CD
VIVOTEK
Ver 1.0
User's Manual - 209
