Set the local time manually:
Input date as yyyy .mm .dd, i .e ., 2013 .9 .30 .
Date:
Time: Input current time as hh:mm:ss, i .e ., 08:50:00 .

DMZ Host

When the NAT mode is activated, users may need to use applications
that do not support virtual IP addresses, such as network games or video
conferencing . We recommend that users map the device actual WAN IP
addresses directly to the intranet virtual IP addresses . Setting up a DMZ host
will allow one host in the LAN to be exposed to the Internet to use services
such as Internet gaming and video conferencing . Access to the DMZ host
from the Internet can be restricted by using firewall access rules . Use the
Configuration > Setup > DMZ Host page .
Enter the LAN IP address of the server that you want to use as a DMZ host .
NOTE Remember to click Save before leaving the page . You can also click
Cancel to undo the changes

Port Forwarding and Port Triggering

You can set up a port forwarding virtual host to allow public access to servers
connected to the LAN ports . Port Forwarding opens a specified port or a port
range for a service, such as FTP, WWW, and mail, etc . Port Triggering opens a
port range for services that use alternate ports to communicate between the
server and LAN host . Use the Configuration > Setup > Forwarding page to
configure .
• Port Range Forwarding
• Port Triggering
NOTE Remember to click Save before leaving the page . You can also click
Cancel to undo the changes .
Setup
16
