Labelling input sources

(Input Label)

You can assign each input source a label as you
prefer.
1
Press COMPUTER (1/2), DVI, HDMI, S-VIDEO or
VIDEO to select the desired input source.
2
Press MENU and the MENU screen appears.
Press ◄/► to select "Setup".
3
Press ▲/▼ to select "Input Label", and then
4
press ENTER.
• When an HDMI input terminal is selected, a
Menu screen for selecting "Auto" or "Manual" is
displayed.
• When you select "Auto" using ▲/▼, the Menu
screen returns to the previous screen.
• When you select "Manual" using ▲/▼, the
screen for labelling the input source appears.
Proceed to step 5.
Press ▲/▼ to select characters and ◄/► to
5
move to the desired digit to label the input source.
• When you want to change the input label
that you have already assigned to the default
name, press ◄/► to move to "CLEAR" on the
"Input Label" screen, and then press ENTER.
6
Repeat the above until the name is fully spelled
out, and then press MENU.
• The name can be 9 characters or less.
• When you want to set an input source name
of less than 9 characters, press MENU to exit
from the labelling menu.

Adjusting the image position

(Position)

For adjusting a picture's horizontal and vertical
position.
Selectable
Items

H-Position

Centers the image by moving it to
the left or right.

V-Position

Centers the image by moving it up
or down.
Note
• For resetting all adjustment items to the factory preset
values, press ▲/▼ to select "Reset", press ENTER,
press ▲/▼ to select "Yes", and then press ENTER.
• Adjustments are stored separately according to input
source.
• Images may not be displayed properly depending on the
settings and/or signals.
Description
Menu operations
Adjusting the computer image

(Fine Sync)

Resolution

Ordinarily, the type of input signal is detected
and the correct resolution mode is automatically
selected. However, for some signals, the optimal
resolution mode on the "Resolution" menu may need
to be selected to match the computer display mode.

Signal Info

Displays infomation about the input signal, such
as resolution, horizontal frequency, and vertical
frequency.
Auto Sync Adjustment (Auto Sync)
Selectable
Description
items
Yes Perform Auto Sync adjustment.
No Do not perform Auto Sync adjustment.
Note
• Auto Sync adjustment is also performed by pressing
AUTO SYNC on the remote control.
• The Auto Sync adjustment may take some time to
complete, depending on the image of the computer
connected to the monitor.
• When the optimum image cannot be achieved with Auto
Sync adjustment, use manual adjustments. (See page
38.)
