Connecting Peripheral Equipment
Terminal on connected
Equipment
Camera/Video game Component
video output
terminal
S-video output
terminal
Video output
terminal
Audio equipment ø3.5 mm audio
output terminal
RCA audio output
terminal
Audio output
terminal
Monitor RGB input
terminal
Amplifi er ø3.5 mm audio
input terminal
RCA audio input
terminal
Note
• When using the ø3.5 mm mono audio cable, the volume level will be half of when using the ø3.5 mm stereo audio cable.
MONITOR OUT terminals
• Audio and images from equipment connected to the COMPUTER IN 1 or COMPUTER IN 2 terminals can
be output from the MONITOR OUT terminals.
18
Cable (commercially available)
equipment
Cables for a camera or a video game/
3 RCA to mini D-sub 15 pin cable
Cables for a camera or a video game
Cables for a camera or a video game
ø3.5 mm stereo or mono audio cable
RCA audio cable
Cables for a camera or a video game
RGB cable
ø3.5 mm stereo or mono audio cable
ø3.5 mm stereo minijack to RCA audio
cable
Terminal on the
COMPUTER IN 1
RCA adaptor plug
S-VIDEO IN
VIDEO IN
AUDIO (for DVI IN)
AUDIO
(for COMPUTER IN 1)
(for COMPUTER IN 2)
AUDIO
(for S-VIDEO IN)
(for VIDEO IN)
MONITOR OUT
AUDIO
(for MONITOR OUT)
monitor
AUDIO
