Specifications; Video; Lens; Operational - Samsung SNZ-5200 Specifications

Dimensions
Unit : mm (inch)
136 (5.35")
Accessories (Optional)
USE OR
WITH
STB-400 STH-500
SHB-4200/SHB-4200H
SHB-4300H1
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Road, Suite 700, Ridgefield Park, NJ 07660, UNITED STATES
Tol Free : 1-877-213-1222 Fax : 1-201-373-0124
www.samsungsecurityusa.com
1.3Megapixel HD 20x Zoom Network Camera
SNZ-5200
1.3M
20x

Specifications

VIDEO

Imaging Device
Total Pixels
Effective Pixels
Scanning System
Min. Illumination
S / N Ratio
Video Output

LENS

Focal Length (Zoom Ratio) 4.45 ~ 89mm (20x)
Max. Aperture Ratio
Angular Field of View
Min. Object Distance
Focus Control
Lens Type
Mount Type
PAN / TILT / ROTATE
Preset
72 (2.83")

OPERATIONAL

Camera Title
Day & Night
Backlight Compensation Off / BLC / HLC
Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization Off / On
Motion Detection
Privacy Masking
Sens-up (Frame Integration) Off / Auto (2x ~ 60x)
Gain Control
White Balance
Electronic Shutter Speed Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Digital Zoom
Flip / Mirror
Intelligent Video Analytics Scene change, Virtual line, Enter / Exit, Appear / Disappear
Alarm I/O
Remote Control Interface RS-485
RS-485 Protocol

NETWORK

Ethernet
Video Compression Format H.264, MPEG-4, MJPEG
Resolution
Max. Framerate
STH-200
Video Quality Adjustment
Bitrate Control Method H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Streaming Capability
Audio I/O
Audio Compression Format G.711 u-law
Audio Communication Bi-directional audio
STB-4150V
IP
Protocol
Security
Streaming Method
Max. User Access
Memory Slot
ONVIF Conformance
Webpage Language
Web Viewer
Central Management Software NET-i viewer

ENVIRONMENTAL

Operating Temperature / Humidity -10°C ~ +50°C (+14°F ~ +122°F) / 20 ~ 80% RH

ELECTRICAL

Input Voltage
Power Consumption

MECHANICAL

Color / Material
Dimensions (WxHxD)
Weight
PoE
D&N ICR
1/3" 1.3M PS CMOS
1,384(H) x 1,076(V)
1,329(H) x 1,049(V)
Progressive
Color : 0.7Lux (F1.2, 50IRE), 0.01Lux (Sens-up 60x, 50IRE)
B/W : 0.08Lux (F1.6, 50IRE), 0.001Lux (Sens-up 60x, 50IRE)
52dB
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
F1.6(Wide) / F2.9(Tele)
H : 56.56˚(Wide) ~ 3.10˚(Tele) / V : 43.32˚(Wide) ~ 2.34˚(Tele)
1m (3.28ft)
AF / One-shot AF / Manual (Remote control via Network)
DC auto iris
Board-in type
128ea
Off / On (Displayed up to 15 characters)
Auto (ICR) / Color / B/W
Off / On (4 programmable zones)
Off / On (8 programmable zones)
Off / Low / Medium / High / Manual
ATW / AWC / Manual / Indoor / Outdoor
16x
Off / On
Input 1ea / Output 1ea (Relay)
Samsung-T/E, Pelco-P/D
RJ-45 (10/100BASE-T)
1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
30fps
H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
Multiple streaming (Up to 10 profiles)
Mic / Line in, Line out
IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Unicast / Multicast
10 users at unicast mode
SD/SDHC memory slot
Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 6.0 or Higher, Firefox, Google Chrome, Apple Safari
12V DC, PoE (IEEE802.3af)
12V DC : Max. 8W, PoE : Max. 7.5W
Dark gray / Metal
72.0 x 60.0 x 136.0mm (2.83" x 2.36" x 5.35")
540g (1.19 lb)
Eco mark
The represents
Samsung Techwin's will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
Design and specifications are subject to change without notice.
SNZ-5200N/P
