Front Panel

AC Power Switch - page 7
Clock Source - page 8
Settings: Internal Clock, Lock to WC / SC, Lock to AES, Lock to DAW Card
Clock Sample Rate - page 8
Settings: 44.1, 48, 88.2, 96, 176.4 and 192 kHz
Clock Status Indication - page 9
Lock Status, Reference Sample Rate, Error Reporting
Source for Digital Outputs - page 10
Settings: Source = Internal A/D Converters, Source = DAW Card
Optical Output Format - page 11
Settings: AES Format, ADAT Format, ADAT S/MUX
Meter Display - page 12
16 Dual-Range 9-Segment LED Meters, Driven from A/D Digital Outputs
Meter Scale and Peak Hold - page 12
Settings: Scale Factor = 1 dB/step or 6 dB/step, Peak-Hold On/Off
ADC16 Instruction Manual - Rev A
2 4
, ADAT S/MUX
Page 6
