© 2011 Char-Broil, LLC Columbus, GA 31902
PRODUCT GUIDE
MODEL 463610512
C-21G0CB
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-800-241-7548.
Printed in China
See rating label on grill for serial number.
Assembly instructions © 2011
09/20/11 • G208-001-190801
