Offset Smoker
Firebox/Tabletop
Grill
Product Guide
Model 11201715
Tools needed for assembly:
Two adjustable wrenches
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal inside
homes, vehicles, or tents.
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American Gourmet®;
Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling That's
All About U®; Keepers of the Flame®; Magneto®; New Braunfels Smoker Company®; Patio Bistro®; Patio Caddie®; Patio Kitchen®; Pro-Sear®; RED®; Quantum®; Santa
Fe®; Sear and Grill®; Sierra®; Signature Series®; Sure2Burn®; The Big Easy®; U®; Wild West Tradition®; and the following marks:
The following are trademarks of W.C. Bradley Co.:America's Legendary Barbeque Company™; Advantage Series™; Auto-Clean™;Chef Tested™; Commercial Series™;
Designer Series™;; Diamond Flame™; Double Chef™; Everybody Outside™; FastStart™; FlavorMaster™; Front Avenue™; Grill 2 Go® Advantage™; Grill 2 Go® Ice™; Hog
and Yard Bird™; H20 Smoker™; Infrared. Grilling's Juicy Little Secret™; Incredible Taste. Infallible Results™; Infrared Inside™; Let's Grill Something Together™; Longhorn™;;
Precision Flame™; Quick2Burn™; QuickSet™; Ready When You Are™; Season, Set, And Savor™; Sizzle On The Grill™; SureFire™; Torchfork™; Trentino™; Universal Grill
Parts™; You Bring the Party™
TEC™ is a trademark of Tec Infrared Grills.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
Estimated Assembly Time: 15 minutes
FOR OUTDOOR USE ONLY
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
®
®
1-800-241-7548
TM REVISION 08
.
42804633 - 12/15/10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Char-Broil 11201715
Summary of Contents for Char-Broil 11201715
-
Page 1: Product Record Information
Parts™; You Bring the Party™ TEC™ is a trademark of Tec Infrared Grills. If you have questions or need assistance during assembly, please call 1-800-241-7548 To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register 42804633 - 12/15/10... -
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING Product Record Information ......1 FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR For Your Safety . -
Page 3: Preparing To Use Your Grill
PREPARING TO USE YOUR GRILL Before cooking with your grill, the following steps should be closely followed to both cure the finish and season the interior steel. Failure to properly follow these steps may damage the finish and/or impart metallic flavors to your first foods. Brush all interior surfaces including grills and grates with vegetable cooking oil. -
Page 4: Cooking Tips
COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate. We recommend using 2 pounds (approximately 30 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes. - Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.
-
Page 6: Limited Warranty
LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*. -
Page 7: Parts List/ Parts Diagram
PARTS LIST Description FIREBOX ASSEMBLY ASH PAN ASSEMBLY DAMPER HANDLE, F/ LID SPRING, F/ LID HANDLE HANDLE, F/ ASH PAN SIDE HANDLE CHARCOAL GRATE COOKING GRATE COOKING GRATE SUPPORT NOT Pictured … HARDWARE PACK … ASSEMBLY MANUAL, ENGLISH … ASSEMBLY MANUAL, SPANISH HARDWARE LIST 1/4-20x1/2”... -
Page 8: Assembly
ASSEMBLY 1/4-20x1/2” screws Total of 4 each To begin assembly, Attach the legs to the underside of the Firebox using 2 each 1/4- 20x1/2” screws and 2 each 1/4-20 flange nuts per leg. Insert screws from inside the firebox - all nuts go on the outside of the firebox. - Page 9 Attach the side handles to each side of the grill using 2 each 1/4-20x1/2 ” screws and 2 each 1/4-20 flange nuts per side. Install flange nuts from inside the grill. Tighten securely. Install the Ash Pan Handle by inserting it into the holes in the Ash Pan. Secure with 2 each 1/4-20 flange nuts. Next, install the damper wheel by inserting a 1/4-20x1/2"...
- Page 10 Slide the Ash Pan into the grill as shown. Place the wire Charcoal grate into the bottom of the grill. Next, place the cast iron Cooking Grates into position Cast Iron Cooking Grates Wingnut Wire Charcoal Grate Your Tabletop grill is now complete. Page 10...
-
Page 11: 11301714 Grill Conversion
CONVERSION OF 11301714 CHARCOAL GRILL TO AN OFFSET SMOKER. This tabletop grill can be used to convert a model 11301714 Charcoal Grill into an offset smoker. Be aware that the conversion involves above average metalworking skills and tools not typically available to the average consumer. Also be aware that once this conversion is complete, it is not reversible. - Page 12 CAUTION: Wear Safety Glasses and Gloves! Next, working from outside the grill, use your hammer and drift punch to bend the screw hole tabs inwards. If the tabs do not break off completely, use your pliers from the inside the grill to twist the tabs until they break off. There are six holes that will need punched out as indicated with circles below.
- Page 13 CAUTION: Wear Safety Glasses and Gloves! Next, working from outside the grill, use your hammer and drift punch to bend the screw hole tabs inwards. If the tabs do not break off completely, use your pliers from the inside the grill to twist the tabs until they break off. There are six holes that will need punched out as indicated with circles below.
- Page 14 Next, install the front Connector Tube by inserting a 1/4-20x2" screw from inside the firebox, through one of the 12x33mm Connector Tubes, then into the 11301714 grill leg bracket. Secure with a 1/4-20 flange nut. Repeat for the rear side. Fully tighten all hardware installed. 1/4-20 Flanged Hex Nut Qty.
-
Page 16: Registration Card
Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240 REGTEMP REV02...
