30" Charcoal Grill
Product Guide
Model 11301672
Tools needed for assembly:
Phillips Screwdriver
Adjustable wrench
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
CAUTION:
Read and follow all safety statements, assembly instructions,
and use and care directions before attempting to assemble
and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal inside
homes, vehicles, or tents.
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American
Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill
Lovers®; Infrared Grilling That's All About U®; Keepers of the Flame®; Magneto®; New Braunfels Smoker Company®; Patio Bistro®; Patio Caddie®; Patio
Kitchen®; Pro-Sear®; RED®; Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature Series®; Sure2Burn®; The Big Easy®; U®; Wild West Tradition®;
and the following marks:
The following are trademarks of W.C. Bradley Co.:America's Legendary Barbeque Company™; Advantage Series™; Auto-Clean™;Chef Tested™;
Commercial Series™; Designer Series™;; Diamond Flame™; Double Chef™; Everybody Outside™; FastStart™; FlavorMaster™; Front Avenue™; Grill 2
Go® Advantage™; Grill 2 Go® Ice™; Hog and Yard Bird™; H20 Smoker™; Infrared. Grilling's Juicy Little Secret™; Incredible Taste. Infallible Results™;
Infrared Inside™; Let's Grill Something Together™; Longhorn™;; Precision Flame™; Quick2Burn™; QuickSet™; Ready When You Are™; Season, Set, And
Savor™; Sizzle On The Grill™; SureFire™; Torchfork™; Trentino™; Universal Grill Parts™; You Bring the Party™
Grills.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
Estimated Assembly Time: 1 Hour
FOR OUTDOOR USE ONLY
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION:
THIS UNIT IS HEAVY! DO NOT attempt to
assemble without a helper.
®
®
1-800-241-7548
TEC™ is a trademark of Tec Infrared
TM REVISION 08
.
42804619 -11301672 - 03/02/11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Char-Broil 11301672
Summary of Contents for Char-Broil 11301672
-
Page 1: Product Record Information
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®;... -
Page 2: Table Of Contents
TABLE OF CONTENTS Product Record Information ......1 Safety Symbols........2 Preparing to use your Grill . -
Page 3: Preparing To Use Your Grill
Re-season your grates frequently, particularly when new. If rust occurs, it is an indication that the grates have not been seasoned enough or the seasoning has been burned off. Clean with a heavy brush like Char-Broil’s Brush Hawg. Reapply vegetable shortening and heat as indicated above to re-season the grates. -
Page 4: Cooking Tips
COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate. We recommend using 2 pounds (approximately 30 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes. - Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.
-
Page 6: Limited Warranty
LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*. -
Page 7: Parts List/ Parts Diagram
PARTS LIST Key Qty Description Lid Assembly Swing-Away Grate Cooking Grate Handle, F/Clean Out Door w/Latch Air Damper Charcoal Pan w/Adjust Assembly Hinge Assembly Left Front Leg, W/Caster Socket Tool Hook Left Rear Leg, W/Caster Socket Firebox Front Panel Firebox Rear Panel Axle Handle, F/Ash Pan Right Front Leg... -
Page 8: Assembly
ASSEMBLY FIRST, GET A HELPER! This unit is heavy and requires a second person for lifting and moving. NEXT, pick a suitable location to work. Open the carton and slit the corners so that the carton lays flat. This will give you a protective surface during assembly. - Page 9 Attach Bottom Shelf to Legs using (4) 1/4-20x2 3/8” Screws. 1/4-20x2 3/8” Screws 1/4-20x2 3/8” Screws Turn grill upside down. Screw (2) Casters into Left Front/Rear Legs and tighten with Flat Wrench provided with grill. Caster Caster Page 9...
- Page 10 Insert a small Hair Pin Clip into the hole at one end of the Axle. Slide a Large Flat Washer and a Wheel onto the Axle. Slide the Axle through the holes at the ends of the Legs. Slide the remaining Wheel onto the Axle. Slide a Large Flat Washer onto the Axle and secure with remaining Hair Pin Clip.
- Page 11 Turn grill right side up. Attach the Air Damper Wheel to the inside of the right side of Firebox using (1) #10-24x3/8” Screw, (1) 5mm Flat Washer and (1) #10-24 Reversible Lock Nut. Repeat for left side of Firebox. DO NOT FULLY TIGHTEN THE LOCK NUT.
- Page 12 Attach Lid Handle and Handle Seats to the Lid using (2) 1/4-20x1/2” Screws. Attach (2) Hinge Assemblies to the rear of Lid using (4) 1/4-20x1 3/8” Screws and (4) 1/4-20 Flange Nuts. Note orientation shown in enlargement. 1/4-20x1 3/8” Screws Page 12 1/4-20x1/2”...
- Page 13 Remove Cap Nut, Spring and Damper from Smoke Stack Body. Insert Smoke Stack Body through hole in Lid. Attach Smoke Stack Body to Lid using (2) 1/4-20x1/2” Screws and (2) 1/4-20 Flange Nuts. Reinstall Damper, Spring and Lock Nut to Smoke Stack Body. Cap Nut Spring Damper...
- Page 14 Remove Flat Washer, Door Latch, Lock Washer and 3/8-16 Nut from Handle. Attach Handle to Clean Out Door, already assembled in Front Panel, by placing a Flat Washer onto the threaded part of Handle. Insert the threaded end of Handle through hole in Clean Out Door. Place the Door Latch onto the threaded end of Handle. Place Lock Washer onto Handle and secure with (1) 3/8-16 Nut.
- Page 15 Attach other Side Shelf to Right Legs using (4) 1/4-20x5/8” Shoulder Screws. Side Shelf Screw Adjuster Crank through front of Firebox. Rotate Adjuster Crank clockwise until Adjuster Crank engages Crank Lever. Insert Hair Pin Clip into Adjuster Crank Shaft. 1/4-20x5/8” Shoulder Screw 1/4-20x5/8”...
- Page 16 Insert straight wire of Swingaway Grid into one side of Lid and then into the other side. Insert angled wire into holes in Firebox. Insert (2) Hair Pin Clips onto holes in straight wire in Lid. Firebox omitted for clarity Place the (3) Cooking Grates into the firebox.
- Page 17 Remove Wingnut from Temperature Gauge. Insert Temperature Gauge through the hole in Lid and attach using Wingnut previously removed. Tighten securely. Temperature Gauge Wingnut Page 17...
-
Page 18: Hardware List
Hardware is shown actual size. You may have spare hardware after assembly is complete. Page 18 HARDWARE LIST 1/4-20 x 2 3/8” Machine Screw Qty. 4 1/4-20 x 1 5/8” Machine Screw Qty. 4 1/4-20 x 1 3/8” Machine Screw Qty. 4 1/4-20 x 1/2”... -
Page 19: Registration Card
Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240 REGTEMP REV02 Page 19...
