Fire Screen
MODEL 11508424
Assembly
Instructions
Tools needed
for assembly:
Phillips screwdriver
Adjustable wrench
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out of ring in breezy conditions. Adequate fire
extinguishing material should be readily available.
WARNING
Do not use this unit on a wood deck or on combustible
surfaces such as dry grass, leaves, mulch, etc. Do not
use this unit near heat sensitive or combustible structures
such as vinyl or wood siding.
CAUTION
Read and follow all safety statements, warnings,
Assembly Instructions and use & care directions before
attempting to assemble.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
FOR
OUTDOOR
USE
ONLY!
Fire Screen 11508424 / 42803951 (01-23-04)
Advertisement
Table of Contents
Related Manuals for Char-Broil 11508424
Summary of Contents for Char-Broil 11508424
- Page 1 Burning charcoal inside can kill you. It gives off carbon fly out of ring in breezy conditions. Adequate fire monoxide, which has no odor. NEVER burn charcoal extinguishing material should be readily available. inside homes, vehicles or tents. Fire Screen 11508424 / 42803951 (01-23-04)
- Page 2 STOP! Missing a part? Call Our Help Line No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line.
- Page 3 Fit the two large screen panels together as shown. Lay the long strip Long strip (with six holes) over the interlocked with six holes screens. Secure with six #8-32x3/16” Large screen machine screws. panel NOTE: Screen panels are shown as solid panels for clarity of illustrations.
- Page 4 Attach the two cover retainers to the back of the large screen section using two #8-32x1/2” machine screws and two #8-32 keps nuts on each side. NOTE: Retainers should curve downward. Large screen section Cover retainer Place small screen section inside large screen section, forming a dome.
- Page 5 Place screen on top of firebowl. Bend the two cover retainers downward, to wrap around edge of firebowl. Bend cover retainer under edge of firebowl.
- Page 6 HARDWARE LIST Hardware is shown actual size. You may have spare hardware after assembly is complete. #8-32x3/4” #8-32x1/2” #8-32x3/16” #8-32 Spacer Machine Screw Machine Screw Machine Screw Keps Nut Qty. 2 Qty. 2 Qty. 4 Qty. 12 Qty. 6 Limited Warranty The manufacturer warrants the product for replacement or repair of parts and/or workmanship for a period of 90 days.
