Char-Broil
Charcoal Grill
Product Guide
Model 11301696
Tools needed for assembly:
Phillips Screwdriver
Flat Head Screwdriver
Adjustable wrench
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
CAUTION:
Read and follow all safety statements, assembly instructions,
and use and care directions before attempting to assemble
and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal inside
homes, vehicles, or tents.
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American Gourmet®;
Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared
Grilling That's All About U®; Keepers of the Flame®; Magneto®; New Braunfels Smoker Company®; Patio Bistro®; Patio Caddie®; Patio Kitchen®; Pro-Sear®;
RED®; Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature Series®; Sure2Burn®; The Big Easy®; U®; Wild West Tradition®; and the following marks:
The following are trademarks of W.C. Bradley Co.:America's Legendary Barbeque Company™; Advantage Series™; Auto-Clean™;Chef Tested™; Commercial
Series™; Designer Series™;; Diamond Flame™; Double Chef™; Everybody Outside™; FastStart™; FlavorMaster™; Front Avenue™; Grill 2 Go® Advantage™;
Grill 2 Go® Ice™; Hog and Yard Bird™; H20 Smoker™; Infrared. Grilling's Juicy Little Secret™; Incredible Taste. Infallible Results™; Infrared Inside™; Let's Grill
Something Together™; Longhorn™;; Precision Flame™; Quick2Burn™; QuickSet™; Ready When You Are™; Season, Set, And Savor™; Sizzle On The Grill™;
SureFire™; Torchfork™; Trentino™; Universal Grill Parts™; You Bring the Party™
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
Estimated Assembly Time: 1 Hour
FOR OUTDOOR USE ONLY
®
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION:
THIS UNIT IS HEAVY! DO NOT attempt to
assemble without a helper.
®
TEC™ is a trademark of Tec Infrared Grills.
1-800-241-7548
.
TM REVISION 08
42804615 - 1/3/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 11301696 and is the answer not in the manual?

Questions and answers

Summary of Contents for Char-Broil 11301696

  • Page 1: Product Record Information

    The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling That’s All About U®;...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING Product Record Information ......1 FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR Safety Symbols.
  • Page 3: Preparing To Use Your Grill

    Re-season your grates frequently, particularly when new. If rust occurs, it is an indication that the grates have not been seasoned enough or the seasoning has been burned off. Clean with a heavy brush like Char-Broil’s Brush Hawg. Reapply vegetable shortening and heat as indicated above to re-season the grates.
  • Page 4: Cooking Tips

    COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate or pan. We recommend using 2 pounds (approximately 30 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes.
  • Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.
  • Page 6: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.
  • Page 7: Parts List/ Parts Diagram

    PARTS LIST Description Description LEG CAP LID ASSEMBLY DOOR, CLEAN OUT FIREBOX FRONT PANEL BOTTOM SHELF FIREBOX BACK PANEL UPPER HINGE, F/LID FIREBOX SIDE PANEL HANGER, F/ CHARCOAL PAN BEZEL, F/LID HANDLE BUTTERFLY DAMPER WHEEL SMOKE STACK ASSEMBLY ASH PAN LOGO PLATE KIT CHARCOAL PAN TEMPERATURE GAUGE...
  • Page 8: Assembly

    ASSEMBLY First, get a helper, this unit is heavy and will require a second person for lifting and moving. Open the carton and lay it flat. This will give you a protective surface during assembly. Assemble firebox side panels to the outside of the firebox back panel using ¼- 20 x ¾” screws and ¼” flange nuts. Make sure to use the top hole and the third hole counting from top down.
  • Page 9 Assemble 2 left legs, 1 right rear leg and 1 right front leg to firebox and bottom shelf . Use four 1/4-20 x 2 ½ "screws for the bottom shelf and eight 1/4-20 x 3/4" screws for firebox, tighten screws as shown in the figure. Note: For easier assembly, lay grill with its front panel to the floor, attach the front legs, and then flip over onto its back panel to attach the back legs Note: When attaching legs, make sure that the top 2 holes on right legs are facing each.
  • Page 10 Attach butterfly damper wheels on outside of grill using two ¼ - 20 x -3/4" screw and two 1/4" flange nut ,do not fully tighten the flange nut, this will allow for smooth rotation of the damper. 1/4- 20 x 3/4” screws 1/4”...
  • Page 11 Assemble charcoal door spacer to charcoal door handle with front door latch and washer by using flange nut as shown. Note: Check orientation of handle during assembly. It should point down when door is latched. 12 mm dia washer Front door latch Door spacer Charcoal door handle 1/4 “...
  • Page 12 Place lid assembly on top of firebox then align hinge holes. Attach lid to firebox using 2 hinge pins . Once hinge pins are in place, insert hitch pin into hole in hinge pins. Hitch pin (2 pieces) Hinge pins (2 pieces) Attach lid handle to lid assembly using 2 handle bezels and two 1/4-20 x 3/4"...
  • Page 13 Iinsert smoke stack assembly into lid attach using two 1/4-20 x 3/4" screws and two 1/4" flange nuts. 1/4 - 20 x 3/4” screw (2 pieces) Smoke stack assembly 1/4” Flange nuts (2 pieces) Attach side shelf assembly to right side of grill using four ¼ - 20 x ½” screws , tighten. Note: For ease of assembly- tighten top screw on each leg before mounting the side shelf.
  • Page 14 Attach ash pan handle to ash pan using two 1/4- 20 x ¾” screws. 1/4 - 20 x 3/4” screws (2 pieces) Ash pan Ash pan handle Insert the completed ash pan into slot underneath the main body of the grill. Page 14...
  • Page 15 Install swing away grate into the holes at the bottom of the lid and at the top of grill firebox. Attach 2 charcoal pan hangers to charcoal pan and place charcoal pan into grill. The charcoal pan hangers will hook onto the tabs on the inside of the grill. Charcoal pan hanger (2 pieces) Charcoal pan...
  • Page 16 Place 2 cast iron cooking grate into the firebox. The cast iron cooking grates will rest on the front and rear edges of the firebox. Cooking grates (2 pieces) Remove nut from temperature gauge. Install temperature gauge into lid assembly and attach using nut. Temperature gauge Page 16...
  • Page 17: Hardware List

    HARDWARE LIST Hardware as shown is not actual size. You may have spare hardware after assembly is complete. 1/4 - 20 x 2 1/2” Screw 4 pieces 1/4” - 20 x 1 ½” Screw 4 pieces 1/4” - 20 x 1 1/4” Screw 4 pieces 1/4”...
  • Page 18 Notes: Page 18...
  • Page 20: Registration Card

    Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240 REGTEMP REV02...
