Simple Scan™
Introduction:
Thank you for purchasing the Simple Scan™ by
American DJ
. The Simple Scan™ is a packaged special effect light-
®
ing system (systems includes; 3 XLR cable, 4 simple scan™ units).
Everything you need for a great portable lighting system is included in
this one package. The system will run in a master/slave configuration,
any of the units can act as masters or as slaves. The units acting as
slaves will react to the programs built into the unit functioning as the
master. The unit functioning as the master will react to an audio signal
via the built-in microphone. The Simple Scan™ is a unique system
each unit includes a bright 150 watt lamp with replaceable gobos and
dichroic lenses. Add the unique lighting effect with the compact and
light case design and you get a completely portable lighting effect
show that can revival many other effects for three times the price. This
system is great for mobile DJ's, bands, and small clubs. The system is
system set up and easy in minutes and packs a powerful light show in
a relatively small package. For best results use this system with a fog
machine or other type of special effect fog to enhance the output of
the colorful beams produced beams.
Customer Support:
American DJ
support line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. For service related issue please contact Ameri-
can DJ
. Service Hours are Monday through Friday 9:00 a.m. to 5:00
®
p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2610
E-mail:
support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this system to rain or moisture.
Caution!
There are no user serviceable parts inside these units. Do
not attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event any of your units require service please
contact your nearest American DJ
PLEASE recycle the shipping carton whenever possible.
American DJ
- www.americandj.com - Simple Scan™ Instruction Manual Page 2
©
®
