American DJ
Caution: Read all instructions before attempting to install or power unit up!
Specifications: DJ Scan
Weight:
Dimensions:
Lamp:
Fuse:
Voltage:
Gobos:
Colors:
Cooling:
Working Position:
DJ Scan™ Introduction
Congratulations and thank you for purchasing the American DJ "DJ Scan," one of the finest pieces of its
kind on the market today! The DJ Scan is a great inexpensive, light weight, mini intelligent fixture. Due to
it's physical specifications, it's a great piece for mobile DJ's, roller rinks, small clubs, bars, and bowling cen-
ters. When used in multiples of two (2) or more, these units create an effect that rivals that of units that can
cost up to three times the price. The DJ Scan™ was designed to run in master/slave mode but can be used
with a standard dmx controller.
DJ Scan™ Features
The DJ Scan features a bright 150 watt/500 Hr lamp life halogen bulb with a separate gobo and color
wheel. The color wheel features seven brilliant colors plus white and the gobo wheel features 9 gobos plus
a large and small spot. This units is ready to be installed or hung and powered right out of the box. There
is no assembly required. This fixture incorporates the use of high quality stepper motors for a more accu-
rate mirror movement. Mirror movement allows for a full 90 degree tilt (vertical) and a full 90 degree
pan (horizontal). An internal built in microphone allows the fixtures to run in Stand Alone mode so there
is no need for an external controller. The DJ Scan™ may also be set-up to run in a Master-Slave mode
when used in multiples, up to 16 units. When used in the Master-Slave mode, the unit will chase to sever-
21 lbs.
18x 8.6 x 4.3
JCR/H5 15v-150w
5
/250v GMA
A
115v/230v, 60Hz/50Hz
10 Plus Spot
7 Plus White
Fan Cooled
Any Safe Position
.
®
American DJ Supply
©
USER
USER
INSTRUCTIONS
INSTRUCTIONS
®
HALOGEN LAMP WARNING!
This fixture is fitted with a halogen lamp which
is highly susceptible to damage if improperly
handled. Never touch lamp with your bare fin-
gers as the oil from your hands may shorten
the lamp life. Also, never move the fixture until
the lamp has had ample time to cool.
Remember, lamps are not covered under war-
ranty conditions.
Los Angeles, CA. 90058 USA DJ Scan Page 1
