American DJ
SUNRAY III
CAUTION!
SPECIFICATIONS: MODEL -
Weight:
16 lbs.
Size:
10" x 10" x 14".
Lamp:
64514 120V 300W
Fuse:
5 AMP
Supply Voltage: 110-120V/60Hz.
Working Position: Any Safe position.
Motor Speed: 6 rpm.
Duty Cycle: 10 min. on, 10 min. off.
FEATURES:
The Sunray III™ features bright focused beams of multi-colored light. This unit is Ideal for a large venues as a
centerpiece. The Sunray III™ includes a mounting. Optional 300W ADJ-300 / 150 hr. Long Life lamp is also available.
INSTALLATION:
After plugging in, unit will rotate slowly at 6 r.p.m. For optimum perfomance of your Sunray III™, please follow its
prescribed Duty Cycle.
Caution: Never open unit when in use. Unplug unit and let cool before servicing. Always remember to replace lamps
and fuses with the same wattage, voltage and amperage ratings. The SUNRAY III™ has no transformer, and is light in
weight.
For lamp replacement; unscrew screw on ball, remove cover, replace lamp & reassemble.
For service, contact your American DJ® Dealer.
EACH UNIT IS LAMPED AND TESTED BEFORE LEAVING THE FACTORY.
Affordable Quality Lighting Products from American DJ® Los Angeles, CA. 90058 USA
®
Read instructions before installing or plugging unit in.
SUNRAY III™
User Instructions
™
HALOGEN LAMP WARNING!
This fixture is fitted with halogen
lamps which are highly suscepti-
ble to damage if impro p e r l y
handled. Never touch lamp with
bare fingers as the oil from your
hands will shorten lamp life. Also,
never move fixture until lamp
has had ample time to cool.
R e m e m b e r, lamps are not cov-
ered under warranty conditions.
