Star Winder™
General Instructions:
DJ
Star Winder.
The Star Winder™ is an intelligent moon-flower effect
®
with a twist. This unit uses a multi-colored dichroic dish overlapped
with a slotted dish. The two dish rotate against each other to create an
unique cross effect. To optimize the performance of this product, please
read these operating instructions carefully to familiarize yourself with
the basic operations of this unit. This unit is sound-active and may be
operated with or without an universal DMX controller such as the Ameri-
can DJ
DMX Operator™ or Show Designer.™ The unit can be linked
®
with several other units to run in a Master/Slave orientation. For best
result use this fixture with fog to enhance the beam output.
Customer Support:
American DJ
support line, to provide set up and installation help and to answer any
question should you encounter problems during your set up or initial
operation. You may also visit us on the web at www.americandj.com
for any comments or suggestions. Toll free customer service hours are
Monday through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2610
E-mail:
support@americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any type of repair yourself without the manufactures consent,
doing so will void your manufactures warranty. In the unlikely event your
unit may require service, contact American DJ
Warning!
The 1/4" phone plug on the unit is for the optional
MINI/C. Do not attempt to connect an audio signal to this jack, this
will damage the PC board and void your manufactures warranty!
Star Winder™
This fixture is fitted with a halogen lamp which is highly susceptible to
damage if improperly handled. Never touch the lamp with your bare
fingers as the oil from your hands will shorten the lamp life. Never
install, mount, or place this fixture in areas prone to heavy vibration.
Also, never move the fixture until the lamp has had ample time to cool.
Remember, lamps are not covered under warranty conditions.
American DJ Supply
- www.americandj.com - Star Winder™ Instruction Manual Page 2
©
®
Introduction
Thank you for purchasing the American
provides a toll free customer
®
customer support.
®
Halogen Lamp Warning

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Star Winder and is the answer not in the manual?

Questions and answers

Summary of Contents for American DJ Star Winder

  • Page 1 There are no user serviceable parts inside this unit. Do not attempt any type of repair yourself without the manufactures consent, doing so will void your manufactures warranty. In the unlikely event your unit may require service, contact American DJ customer support. ®...
  • Page 2: Table Of Contents

    D. The appliance does not appear to operate normally or exhibits a • Fan Cooled. marked change in performance. • Optional MINI/C Blackout Controller. American DJ Supply www.americandj.com Star Winder™ Instruction Manual Page 4 American DJ Supply www.americandj.com Star Winder™ Instruction Manual Page 3 ©...
  • Page 3: Set-Up

    When longer runs of cable are Before plugging your unit in, be sure the source volt- age in your area matches the required voltage for your American DJ used, you may need to use a terminator on the last unit to avoid erratic ®...
  • Page 4: Linking

    8. Power Cord - Connect only to a matching power outlet. Never use this fixture is the ground prong has been removed or broken off. American DJ Supply - www.americandj.com - Star Winder™ Instruction Manual Page 7 American DJ Supply - www.americandj.com - Star Winder™...
  • Page 5: Operation

    Always replace with the exact same type fuse, unless other- running a single unit, or when running several units as individuals. wise instructed to do so by an authorized American DJ service tech- nician. 1. To activate the Sound-Active mode, set dip switches #1 and #10, 10.
  • Page 6: Lamp Replacement

    Cleaning frequency depends on the environment in which the fixture operates (i.e. smoke, fog residue, dust, dew). American DJ Supply - www.americandj.com - Star Winder™ Instruction Manual Page 12 American DJ Supply - www.americandj.com - Star Winder™ Instruction Manual Page 11 ©...
  • Page 7 Please follow standard binary DMX protocol as described on page 6 for proper dip switch settings beyond the sixteenth unit or for units not starting at DMX channel one. For the American DJ DMX Operator™ setting please refer to the DMX ®...
  • Page 8: Warranty

    ® parts at its expense, and will absorb all expenses for warranty service and repair labor by written notice. reason of defects in material or workmanship. The sole responsibility of American DJ under ® this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of American DJ .
