- Page 2 SAFETY NOTES To reduce the risk of electrical shocks, fire, and related hazards: Do not remove screws, cover, or cabinet. There are no user serviceable parts inside. Refer servicing to qualified service personnel. Do not expose this device to rain, moisture or spillover of liquid of any kind. Do not insert foreign objects into the ventilation outlets of the cabinet.
- Page 3 CONTENTS Introduction ................... Product Overview ................Front Panel ..................Rear Panel ..................Wiring Diagram ................Installation and Connection ............Operation ..................Technical Specifications ..............
-
Page 4: Product Overview
Introduction Thank you for purchasing this 10M Rubidium Atomic Clock the foremost device in the Antelope's ISOCHRONE product line specifically designed for the most discerning audio professionals. Before you begin operating this unit, please read the instructions carefully to make sure you handle the device properly and get the best possible performance. - Page 5 Once the device is fully warmed up, the message is replaced by "10M" which means maximum stability has now been achieved (the clock frequency stability meets specifications) and the device is ready for use.
- Page 6 BNC outlets for the 10 MHz atomic clock signal. For best results, the cables should not exceed 6 meters (20 feet) in length. Longer cable runs result in increased jitter and other clock errors. WIRING DIAGRAM Example connection schematics of the ISOCHRONE 10M.
- Page 7 The device should not be placed next to any heat-sensitive piece of equipment. (The surface of ISOCHRONE 10M may reach a temperature of 55°C (140°F) during operation.) To minimize frequency instabilities, the device should not be placed near equipment generating strong magnetic fields, such as generators, transformers, etc.
- Page 8 100-240V AC ~ 50/60Hz (unload) , 11 lb.
