Description:
This range of light weight, flameproof horns has been
designed with a high weatherproof rating to cope with the
harsh environmental conditions found offshore and onshore
in the oil, gas and petrochemical industries.
New electronic circuitry allows the DB1P and DB1HP to be
switched between two selectable tones by either reversing
the supply polarity, or connecting a second voltage supply.
The higher output are particularly suitable for noisy environ-
ments.
Architects and Engineers Specifications
Explosion-proof horns shall be UL Listed for Class I, Division 1, Groups C&D, and Class I, Zone 1 hazardous locations. The horns
shall be constructed of marine grade alloy with an epoxy paint finish and shall meet NEMA 4x and IP 66 environmental requirements
over a temperature range of -13°F to 158°F (-25°C to 70°C) in hazardous and harsh environments.
The horns shall have 27 user selectable output tones. Multiple horns shall be able to operate in synchronization. Rated current draw
at 24 vdc shall not exceed 250 mA for rated sound output of 93 dBA at 10 feet or 700 mA for rated sound output of 100 dBA at 10 feet.
The horns shall be capable of direct surface mounting.
Note: Due to continuous development of our products, specifications and offerings are subject to change without notice in accordance
with Cooper Wheelock standard terms and conditions.
ATEX
Horn - 103dB, Explosion Proof, High Output
Features*:
UL Listed – Class I, Div 1. Groups C & D
★
Class I, Zone 1 and Zone 2 use
★
ATEX approved
★
NEMA 4x, IP66
★
Certified temperature –13°F to +158°F (–25°C to
★
+70°C)
NFPA 72 compliant
★
4 wire diode monitored connection for operation
★
in supervisory mode
Up to 103 dBA output @ 10 feet
★
Marine grade alloy
★
Up to 27 output tones, user selectable
★
12V, 24V & 48 VDC, 110 VAC
★
Tones can be selected remotely
★
Any two tones may be switched via the external
★
voltage supply
*Depends on version
DB1
