Cooper Wheelock Series NS Specification

Description:
The Series NS Horn Strobe Appliances are designed for indoor,
wall and ceiling mount applications.
The Series NH Horn and the horn portion of the Series NS include
a selectable continuous horn tone or temporal pattern (Code 3) with
selectable dBA settings of 90 or 95 dBA.
Strobe options include 1575cd or the Wheelock patented
Multi-Candela strobe with field selectable candela settings of
15/30/75/110cd for wall mount and 15/30/75/95cd and 115/177cd
for ceiling mount.
These versatile Horn Strobe Appliances can be synchronized using
the Wheelock SM, DSM Sync Modules or the PS-24-8MC Power
Supply with the Wheelock patented Sync Protocol. Additionally, the
audible may be silenced while maintaining strobe activation.
All models of the Series NS and NH are designed for maximum
performance, reliability and cost-effectiveness while meeting or
exceeding the latest requirements of NFPA 72/ANSI 117.1/UFC and
UL Standards 1971 and 464 as well as meeting ADA requirements
concerning photosensitive epilepsy.
The Wheelock patented 2-Wire Series NS Horn Strobes and
Series NH Horns offer more features with lower current draw than
competitors.
U
THE CITY OF
NEW YORK
L
®
DEPARTMENT OF BUILDINGS
E5946
151-92-E
7125-0785:142
S5391
Series NS Horn Strobes and Series NH Horns
Series NS Series NH
Features:
• Approvals include: UL Standard 1971, UL Standard 464,
New York City (MEA), California State Fire Marshal (CSFM),
Factory Mutual (FM) and Chicago (BFP). See approvals by
model number in Specifications and Ordering Information
• ADA/NFPA/UFC/ANSI compliant
• Complies with OSHA 29, Part 1910.165
• Wall mount model Field Selectable Candela Setting
15/30/75/110cd (24 VDC Multi-Candela models) or 1575cd in
12 or 24 VDC
• Ceiling mount model Field Selectable Candela Setting
15/30/75/95cd and 115/177cd (24 VDC Multi-Candela
models)
• Selectable Continuous Horn or Temporal (Code 3)
• 2 Selectable dBA settings of 90 and 95 dBA in both tones
• Patented Universal Mounting Plate
• 12 and 24 VDC models with UL "Regulated Voltage" using
filtered DC or unfiltered VRMS input voltage
• Wall and Ceiling Mount
• Ceiling models with same look as Wheelock round ceiling
strobes and speakers
• NH horn is selectable 12 or 24 VDC in 1 appliance
• The strobes can be synchronized using the Wheelock sync
modules or power supplies with built in Sync Protocol
• Fast installation with IN/OUT screw terminals using #12 to
#18 AWG wires
