Cooper Wheelock Series ZNS Specification

SNAP
Description:
The Wheelock Series Z notification appliances feature an easy snap
on base that is designed to simplify the installation and testing of
horns, strobes, and horn/strobes. The separate Series Z snap on
base can be pre-wired so circuit wiring can be fully tested before
the appliance is installed and before the walls are covered. Once
all surrounding work is complete, the appliance can be simply
installed by snaping it on the base. Shorting contacts in the base,
which provide continuity for circuit testing, are permanently opened
when the appliance is installed so any subsequent removal of the
appliance will indicate a trouble condition on that circuit at the control
panel when circuit supervision is enabled. The same base is used
for all Series Z horns, strobes and horn/strobes to provide consistent
installation and easy replacement of appliances if required. A locking
screw is also included for the appliance to provide extra secure
installation.
The Wheelock Series Z appliances incorporate the same dependable
circuitry and high efficiency optics that are used in Wheelock RSS
strobes, NS horn/strobes and NH horns and have the same high
performance ratings. The Series Z appliances are compatible with
all UL listed "Regulated" panels and all panels that are compatibility
listed with Wheelock RSS, NS and NH appliances.
ZNS, ZNH and ZRS
appliances go onto the
base plate in a SNAP.
Series ZRS Strobes, ZNS Horn Strobes and Series ZNH Horns
Series ZNS
Series ZNH Series ZRS
Features:
• Approvals include: UL Standard 1971, UL Standard 464,
New York City (MEA), California State Fire Marshal (CSFM),
Factory Mutual (FM) and Chicago (BFP). See approvals by
model number in Specifications and Ordering Information
• ADA/NFPA/UFC/ANSI and OSHA 29, Part 1910, 165
compliant
• EZ Mount SNAP design, with separate base plate, provides
ability to pre-wire the base and test the circuit wiring before
the walls are covered
• The base plate is protected by a disposable cover and the
appliances can quickly snap onto the base after the walls are
painted.
• Patented EZ Mount Universal Mounting Plate (ZBASE)
– uses single plate for ceiling and wall mount installations
• Wall Mount models feature field selectable candela settings
of 15/30/75/110cd and 135/185cd
• Ceiling Mount models feature field selectable candela
settings of 15/30/75/95cd and 115/177cd
• Strobes can be synchronized using the Wheelock sync
modules or power supplies with built-in sync protocol
• 12 and 24 VDC models with UL "Regulated Voltage" using
filtered DC or unfiltered VRMS input voltage
• Strobes produce 1 flash per second over the "Regulated
Voltage" range (ZNS, ZRS models)
• Selectable Continuous Horn or Temporal (Code-3) Tones with
selectable 90 or 95 dBA setting (ZNH, ZNS models)
• Selectable 12 or 24VDC in 1 appliance (ZNH model)
Series ZRS
