- Page 1 Hoshizaki Hoshizaki America, Inc. Modular Crescent Cuber Models KM-901MAH50 KM-901MRH50 INSTRUCTION MANUAL “A Superior Degree of Reliability” www.hoshizaki.com ™ Issued: 6-21-2010...
- Page 2 Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, write, or send an e-mail message to the Hoshizaki Technical Support Department for assistance. HOSHIZAKI AMERICA, INC.
-
Page 3: Table Of Contents
CONTENTS Important Safety Information ....................4 I. Specifications ........................5 A. Nameplate Rating ......................5 1. KM-901MAH50 (air-cooled) ..................5 2. KM-901MRH50 (remote air-cooled) ................ 6 B. Dimensions/Connections ....................7 1. KM-901MAH50 ......................7 2. KM-901MRH50 ......................8 II. -
Page 4: Important Safety Information
Important Safety Information Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. WARNING Indicates a hazardous situation which could result in death or serious injury. CAUTION Indicates a situation which could result in damage to the unit. -
Page 5: Specifications
I. Specifications A. Nameplate Rating 1. KM-901MAH50 (air-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KM-901MAH50 SERIAL NUMBER AC SUPPLY VOLTAGE 230V FREQUENCY 50HZ ELECTRICAL CONSUMPTION 2157W COMPRESSOR CONSUMPTION 1921W AMPERAGE 9.0A STARTING AMPERAGE REFRIGERANT 404A 1375G WEIGHT 116KG MAXIMUM OPERATING PRESSURE 2.88MPA... -
Page 6: Km-901Mrh50 (Remote Air-Cooled)
2. KM-901MRH50 (remote air-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KM-901MRH50 SERIAL NUMBER AC SUPPLY VOLTAGE 230V FREQUENCY 50HZ ELECTRICAL CONSUMPTION 2222W COMPRESSOR CONSUMPTION 1961W AMPERAGE 9.2A STARTING AMPERAGE REFRIGERANT 404A 2420G WEIGHT 113KG MAXIMUM OPERATING PRESSURE 2.88MPA LEAK TIGHTNESS TESTED... -
Page 7: Dimensions/Connections
B. Dimensions/Connections 1. KM-901MAH50... -
Page 8: Km-901Mrh50
2. KM-901MRH50... -
Page 9: Installation And Operating Instructions
• See the nameplate on the rear panel, and check that your voltage supplied corresponds with the voltage specified on the nameplate. • This icemaker can be installed on a storage bin 30" wide or wider. Hoshizaki Ice Storage Bin, Model B-500 series is recommended. For further options, contact your local Hoshizaki distributor. • On remote air-cooled model, a remote condenser unit is needed. Hoshizaki Remote Condenser Unit, Model URC-9F is recommended. B. How to Remove Panels See Fig. 1... -
Page 10: Location
C. Location CAUTION 1. This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within 45°F to 100°F (7°C to 38°C); Normal operating water temperature should be within 45°F to 90°F (7°C to 32°C). Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect icemaker performance. -
Page 11: Electrical Connection
6. To reduce the risk of electric shock, make all remote condenser unit connections before connecting the icemaker power supply. 7. On remote air-cooled models, the icemaker should have power for a minimum of 4 hours prior to startup to prevent compressor damage. • Usually an electrical permit and services of a licensed electrician are required. • The maximum allowable voltage variation is ±10 percent of the nameplate rating. • The opening for the power supply connection is 7/8" DIA to fit a 1/2" trade size conduit. KM-901MAH50 KM-901MRH50 4A1169-011 Fig. 3... -
Page 12: Installation Of Remote Condenser Unit
F. Installation of Remote Condenser Unit WARNING 1. Installation of remote condenser unit must be performed by properly trained and certified service personnel. 2. Failure to install the equipment within these guidelines may adversely affect safety, performance, component life, and warranty coverage. 1. -
Page 13: Setup
4. Line Set CAUTION The icemaker, line set, and remote condenser unit must contain the same type of refrigerant. Mixing of refrigerants will result in improper operation and possible damage to the refrigeration system. • Precharged factory line sets, available as optional equipment from Hoshizaki America, are recommended. For details, see "II.F.4.a) Factory Line Set Installation." Field fabricated line sets are allowed. For details, see "II.F.4.b) Field Fabricated Line Set Installation." • The maximum line length for the standard refrigerant charge is 66 feet. With additional refrigerant, the maximum line length is 100 feet. For details, see "II.F.5. Refrigerant Charge (Line Set Exceeding 66 Feet)."... -
Page 14: B) Field Fabricated Line Set Installation
2) Insulate the two copper tubes separately. 3) Install Parker quick connect couplings on each end. OS-QUICK , a universal quick connect coupling kit available as optional equipment from Hoshizaki America, is recommended. CAUTION! Before brazing, remove the Schrader valve core from the access port. - Page 15 6) Evacuate through the Schrader access ports on the Parker quick connect couplings and charge with R-404A refrigerant vapor to a pressure of 15 to 30 PSIG. 7) Connect the refrigerant lines to the appropriate male fittings on the remote condenser unit first and then at the icemaker.
-
Page 16: Refrigerant Charge (Line Set Exceeding 66 Feet)
The maximum line length for the standard refrigerant charge is 66 feet. Should an installation require a longer line length, additional refrigerant must be added. Add 0.4 oz. of R-404A for each foot over 66 feet to a maximum of 100 feet. Hoshizaki Technical Support is available at 1-800-233-1940 for recommendations. -
Page 17: Stacking Remote Condenser Units
4) Connect the fan motor leads in the junction box of the remote condenser unit to the fan motor leads in the fan motor junction box of the icemaker. Use wire of an appropriate gage and outdoor rating. 5) Replace the junction box covers and the louver panel in their correct positions. Remote Condenser Unit Icemaker Screws... -
Page 18: Water Supply And Drain Connections
10 PSIG. Do not run the icemaker until the proper water pressure is reached. • A plumbing permit and services of a licensed plumber may be required in some areas. • External filters, strainers, or softeners may be required depending on water quality. Contact your local Hoshizaki distributor for recommendations. • Water supply pressure should be a minimum of 10 PSIG and a maximum of 113 PSIG. If the pressure exceeds 113 PSIG, the use of a pressure reducing valve is required. • The icemaker and condensation drain line(s) and storage bin drain line must be run separately. - Page 19 Drain Outlet 3/8" OD Tube Bin Drain Outlet 3/4" FPT Separate piping to approved drain. Leave a two-inch (5 cm) vertical air gap between the end of each pipe and the drain. Two-inch (5 cm) air Floor Drain KM-901MAH50 and KM-901MRH50 Fig. 12...
-
Page 20: Final Checklist
H. Final Checklist WARNING CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the storage bin. 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) and the water temperature within 45°F to 90°F (7°C to 32°C) all year around? 3) Is there at least 6" (15 cm) clearance at sides, rear, and top of the icemaker for proper air circulation and ease of maintenance and service? -
Page 21: Startup
I. Startup WARNING 1. All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. 2. If the icemaker is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the compressor. 3. -
Page 22: Cleaning And Maintenance
A. Cleaning and Sanitizing Instructions Hoshizaki recommends cleaning and sanitizing this unit at least once a year. More frequent cleaning and sanitizing, however, may be required in some existing water conditions. -
Page 23: Sanitizing Procedure - Following Cleaning Procedure
7) Pour the cleaning solution into the water tank. 8) Move the control switch on the control box to the "WASH" position. 9) Replace the insulation panel and the front panel in their correct positions. 10) Turn on the power supply to start the washing process. 11) Turn off the power supply after 30 minutes. 12) Remove the front panel. -
Page 24: Maintenance
12) Clean the storage bin liner using a neutral cleaner. Rinse thoroughly after cleaning. 13) Turn on the power supply to start the automatic icemaking process. B. Maintenance This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. - Page 25 3) Close the icemaker water supply line shut-off valve, then open the icemaker water supply line drain valve. 4) Allow the line to drain by gravity. 5) Attach a compressed air or carbon dioxide supply to the icemaker water supply line drain valve.
- Page 26 HOSHIZAKI AMERICA, INC. 618 Hwy. 74 S., Peachtree City, GA 30269 USA TEL (770) 487-2331 FAX (770) 487-3360 www.hoshizaki.com 91A1JP10A...
