Note:
1. "Mode No." setting is done in a batch for the group. To make or confirm settings for an individual unit, set
the internal mode number in parentheses.
2. The figure of the ceiling height is for the all round outlet. For the settings for four-direction (part of corner
closed off), three-direction and two-direction outlets, see the installation manual and technical guide sup-
plied with the separately sold closure material kit.
11-2 Setting of air direction
• See the installation manual included with the sealing material of air discharge outlet kit, sold separately and
technical guide, for ceiling height settings for two and three-direction air discharge.
(The SECOND CODE NO. is factory set to "01" (all round outlet) before shipping.)
11-3 Settings for Mounting Options
• When installing an option sold separately, refer to the installation manual provided to the option.
11-4 Setting air filter sign
• Remote controllers are equipped with liquid crystal display air filter signs to display the time to clean air filters.
• Change the SECOND CODE NO. according to "Table 5" depending on the amount of dirt or dust in the room.
(SECOND CODE NO. is factory set to "01" for filter contamination-light.)
Table 5
Setting
Air filter contamination-light
Air filter contamination-heavy
No Display
Note:
1. "Mode No." setting is done in a batch for the group. To make or confirm settings for an individual unit, set
the internal mode number in parentheses.
2. Make settings for "No Display" in cases where no cleaning display is required, e.g., at the time of regular
maintenance servicing.
• The air conditioner is provided with a long life filter as a standard accessory. Explain to the customer the
necessity of cleaning the filter periodically along with the set time for filter cleaning for the prevention of
clogging.
When using wireless remote controllers
• When using wireless remote controllers, wireless remote controller address setting is necessary. Refer to
the installation manual attached to the wireless remote controller for setting instructions.
• Set the remote controller to the field set mode. For details, refer to the "HOW TO SET IN THE FIELD", in
the remote controller manual.
• When in the field set mode, select mode No. 12, then set the first code (switch) No. to "1". Then set second
code (position) No. to "01" for FORCED OFF and "02" for ON/OFF OPERATION. (FORCED OFF at factory
set)
English
Spacing time of display air filter
sign (long life type)
Approx. 2500 hrs
Approx. 1250 hrs
FIRST CODE
Mode No.
NO.
0
10 (20)
3
SECOND
CODE NO.
01
02
25
