START-IT
Jump-Start System
260 PSI AIR COMPRESSOR and
12 VOLT DC POWER SUPPLY
IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR
PURCHASE CALL TOLL FREE (866) 584-5556. IN MOST
CASES A SERVICE REPRESENTATIVE CAN RESOLVE
YOUR PROBLEM OVER THE PHONE.
KEY INFORMATION YOU SHOULD
KNOW:
• Jump-start any engine system
with a standard 12 Volt DC
battery
• Easy-to-read series of LED
charge indicators
• Jump-Start System can be
recharged from any standard
110/120 Volt AC power
source
• Built-in Area Light
BEFORE RETURNING THIS PRODUCT FOR ANY REASON,
PLEASE CALL TOLL FREE (866) 584-5504
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,
OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. READ
CAREFULLY BEFORE USE, AND RETAIN FOR FUTURE REFERENCE.
OWNER'S MANUAL AND
WARRANTY INFORMATION
VEC022DSCC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the START-IT VEC022DSCC and is the answer not in the manual?

Questions and answers

Related Manuals for Vector START-IT VEC022DSCC

Summary of Contents for Vector START-IT VEC022DSCC

  • Page 1 VEC022DSCC START-IT Jump-Start System 260 PSI AIR COMPRESSOR and 12 VOLT DC POWER SUPPLY IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR PURCHASE CALL TOLL FREE (866) 584-5556. IN MOST CASES A SERVICE REPRESENTATIVE CAN RESOLVE YOUR PROBLEM OVER THE PHONE.

  • Page 2: Table Of Contents

    CONTENTS 1. INTRODUCTION ..................5 2. FRONT PANEL ....................7 3. VECTOR JUMP-START SYSTEM ..............8 3.1 Jump-starting Instructions ..............9 4. CHARGING/RECHARGING ................10 4.1 110/120 Volt AC Charging ..............10 4.2 12 Volt DC Charging ................11 4.3 Replace Fuse..................11 4.4 Estimated Battery Life ................11 5.
  • Page 3 SAFETY INFORMATION WARNING: Warning statements identify conditions or practices that may result in personal injury or loss of life 1. When working with lead acid batteries, always make sure immediate assistance is available in case of accident or emergency. 2. Always use protective eyewear when using this product: contact with battery acid may cause blindness and/or severe burns, be aware of first aid procedures in case of accidental contact with battery acid.
  • Page 4 10. Check unit periodically for wear and tear. Replace worn or defective parts immediately. Contact Vector Customer Service department toll-free 866-584-5504. 11. Do not attempt to jump-start a frozen battery.

  • Page 5: Introduction

    110/120 Volt AC power supply. It can also be used as a safe, portable source of 12 Volt DC electric power in remote locations and/or emergency situations. It is ideal for use with Vector 12 Volt DC cordless, portable, rechargeable products and MAXXSST DC/AC Power Inverters.
  • Page 6 Figure 1A. Front View Figure 1B. Rear View 12 Volt DC Outlet 14. Alternator Test Push Button AC Recharge Adapter Barrel 15. Charge Level Push Button Connector Receptacle 16. Area Light Push Button Built-in Area Light 17. UP PSI Push Button Negative (-) Black Clamp 18.

  • Page 7: Front Panel

    2. FRONT PANEL Indicators Each indicator has a distinctive meaning. For instance the; FAULT LED indicates the clamp/cable connection is reversed. REVERSE CABLES will appear on the LCD display. Once the clamps/cables are connected correctly, READY TO START will appear on the LCD display. ALARM sounds to indicate there is a low battery function.

  • Page 8: Vector Jump-Start System

    6. Check unit periodically for wear and tear. Replace worn or defective parts immediately; contact Vector Customer Service Department toll-free: (866) 584- 5504 or through our Internet address: www.vectormfg.com. 7. Do not attempt to jump-start a frozen battery.

  • Page 9: Jump-Starting Instructions

    6. This VECTOR® jump-starter is equipped with an internal, automatic safety switch. This switch only activates when connections to the battery are correctly made positive (+) to positive (+) and negative (-) to negative (-). An incorrect connection will sound an audible alarm indicating an incorrect connection.

  • Page 10: Charging/Recharging

    15 minutes and SEEK IMMEDIATE MEDICAL ATTENTION 4. CHARGING/RECHARGING For maximum battery life, we recommend the VECTOR®Jump-Start system be kept fully charged at all times. If the battery is allowed to remain in a discharged state, battery life will be shortened.

  • Page 11: Volt Dc Charging

    NOTE: The unit cannot be overcharged using the AC method. The VECTOR® Jump-Start System also comes with a DC/DC charging adapter for recharging the unit from a 12 volt DC accessory socket in a vehicle or boat. DC recharging method will NOT recharge the unit as effectively as recharging from a 110/120 volt AC outlet.

  • Page 12: Emergency/Area Light

    DRAW MORE THAN 5 AMPS DC Table II shows the estimated 12 volt DC operation time when using a fully charged system. Table II - VECTOR® Jump-Start System as a 12 Volt DC Power Supply Appliance Estimated Power Usage Operating Time...

  • Page 13: Warnings For Compressor Use

    7.2 TIRE INFLATION OR PRODUCTS WITH A VALVE STEM 1. Place connector (chuck) on valve stem. 2. Push connector toward valve stem and close thumb latch. 3. Make sure connector is pushed onto valve stem as far as possible before closing thumb latch.

  • Page 14: Replacement Parts

    For replacement parts (bulbs, batteries, fuses, etc.), contact Vector Customer Service: (954) 584-4446 or toll-free (866) 584-5504. 8.1 BATTERY REPLACEMENT It is recommended that the unit be returned to Vector Customer Service for battery replacement: Contact (954) 584-4446 or toll-free (866) 584-5504. WARNING: •...
