Iiyama ProLite T2233MSC Specification

DISPLAY CHARACTERISTICS
Diagonal
Touchtechnology
Panel
Glass hardness
Display area h x w
Response time
Contrast
Brightness
Viewing zone
Display colour
Pixel pitch h x v
Native resolution Full HD 1080p, 1920 x 1080 ( 2.1 megapixel)
Horizontal sync
Vertical sync
Synchronization
Aspect ratio
Light transmittance
POWER MANAGEMENT
Power supply
Power Supply Unit
Power usage
Power management
DIMENSIONS & WEIGHT
Dimensions w x h x d
Weight
All trademarks and registered trademarks acknowledged. E & O E. Specification subject to change without notice. All LCD's comply with ISO-9241-307:2008 in connection with pixel defects.
www.iiyama.com
The ProLite T2233MSC 22" multi touch screen is based on projected
capacitive technology which thanks to a glass overlay covering the screen
guarantees high durability, scratch-resistance and perfect picture
performance. The touch function remains unaffected even if the glass is
scratched. In addition the bezel free design creates an eye-catching finish
with high light transmission guaranteeing excellent picture clarity and
brilliant colours. All the multi touch functionality is available, including
browsing the web, emailing and drawing on multiple screens, docking and
or typing on the on-screen keyboard. You can scroll and rotate pictures,
draw, zoom in and out using a variety of gestures. The multi-touch is not
only fast but also fun to work with. The panel features High Definition 1920
x 1080 resolution with a 5msec response time. Analogue and DVI inputs
are available for flexible connectivity along with USB for the Touch
Interface. The multi touch function is supported only under Windows® 7/
8.
21.5"
projective capacitive, multitouch (2
compatible touch points - supported only
under Windows® 7/ 8), activated by finger
TN
7H minimum
268.11 x 476.64 mm; 10.6" x 18.8"
5 ms
1000 : 1 with touch panel
270 cd/m² with touch panel
horizontal/vertical: 170°/ 160°; right/left:
85°/ 85°; up/down: 80°/ 80°
16.7 million
0.248 x 0.248 mm
31,5 - 82 KHz
56 - 75 Hz
Separate Sync
16 : 9
90%
AC 100 - 240 V, 50 / 60 Hz
internal
45 W typical; max. 3 W in Power
management mode
VESA DPMS
539 x 384 x 287 mm
10.3 kg
1/1
INTERFACES CONNECTORS
Analog input connector
Digital input connector
Inputs
SPECIAL FEATURES
Controls On-Screen-Display in 7 languages (DE, EN,
User controls contrast, brightness, auto adjust, H.position,
Speakers
Anti-theft-device
Safety
Tilt angle
VESA mounting
Colour
ACCESSORIES
Driver
Included accessories
ProLite T2233MSC
VGA (D-Sub)
DVI-D
USB
ES, FR, IT, JP, Chinese - traditional and
simplified) and 5 front controls (Menu, Scroll
up/ Brightness, Scroll down/ Mute, Select/
Auto, Power)
V.position, H.size, phase, OSD H.position,
OSD V.position, OSD timeout, reset, input
select, OSD language, colour temperature,
volume, mute
2 x 2 W (Stereo)
Kensington-lock™ prepared
CE, TÜV/Bauart, VCCI
90° up; 5° down
100 x 100 mm
Black
multi-touch: Windows7/8 (HID compliant),
single-touch: Vista, XP, 9X, 2000, CE, NT4,
Linux, Mac (OSX)
power cable, D-Sub signal cable, DVI-D
signal cable, audio cable, USB cable, Touch
Panel Driver Disk (CD-ROM), screw, quick
start guide, safety guide
