Operator's Manual
Gasoline containing up to 10% ethanol (E10) is accept-
able for use in this machine. The use of any gasoline ex-
ceeding 10% ethanol (E10) will void the product warranty.
Owner's Manual
YTH22K42
Please read the operator's manual carefully and make sure
you understand the instructions before using the machine.
115 53 05-27
English

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna YTH22K42

Summary of Contents for Husqvarna YTH22K42

  • Page 1 The use of any gasoline ex- ceeding 10% ethanol (E10) will void the product warranty. Owner's Manual YTH22K42 Please read the operator's manual carefully and make sure you understand the instructions before using the machine.

  • Page 2: Safety Rules

    SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Never leave a running machine unattended. Always turn WARNING: In order to prevent ac ci den tal off blades, set parking brake, stop engine, and remove starting when setting up, trans port ing,...
  • Page 3 SAFETY RULES Safe Operation Practices for Ride-On Mowers III. CHILDREN • If fuel is spilled on clothing, change clothing immediately. • Never overfill fuel tank. Replace gas cap and tighten securely. WARNING. CHILDREN CAN BE INJURED BY THIS EQUIPMENT. The American Academy GENERAL SERVICE of Pediatrics recommends that children be a •...

  • Page 4: Table Of Contents

    PRODUCT SPECIFICATIONS CONGRATULATIONS on your purchase of a new tractor. It has been designed, engineered and manu fac tured to give you the best possible dependability and performance. Gasoline Capacity 3.0 Gallons/11,35 L and type: Regular Unleaded Should you experience any problem you cannot easily remedy, please contact your nearest authorized service Oil Type: SAE 10W30 (above 32°F/0°C)

  • Page 5: Assembly

    UNASSEMBLED PARTS Keys Slope Sheet Battery (1) Oil Drain Tube (2) Hex Bolts (1) Quick Connect (2) Nut Keps Key(s) ASSEMBLY Your new tractor has been assembled at the factory with the exception of those parts left unassembled for shipping purposes. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier.

  • Page 6: Assembly

    ASSEMBLY ✓ CHECKLIST NOTE: You may now roll your tractor off the skid. Follow the BEFORE YOU OPERATE YOUR NEW TRAC TOR, WE WISH TO ASSURE THAT YOU RECEIVE THE BEST instructions below to remove the tractor from the skid. PERFORMANCE AND SATISFACTION FROM THIS WARNING: Before start ing, read, un der stand and fol low QUALITY PRODUCT.

  • Page 7: Operation

    OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. FAST SLOW REVERSE HIGH NEUTRAL CHOKE IGNITION SWITCH ENGINE START MOWER HEIGHT MOWER LIFT REVERSE ENGINE ON PARKING BRAKE ENGINE OFF OPERATION SYSTEM (ROS) CLUTCH/BRAKE...
  • Page 8 OPERATION KNOW YOUR TRACTOR READ THIS MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Fig. 3 Our tractors conform to the applicable safety standards of the American National Standards Institute.
  • Page 9 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles.
  • Page 10 OPERATION TO MOVE FORWARD AND BACKWARD • Put attachment lift lever in desired cutting height slot. (See Fig. 7) • Slide pointer tab (T) to desired cutting height as a reminder for next time you mow. The direction and speed of movement is controlled by the forward and reverse drive pedals.
  • Page 11 OPERATION TO STOP MOWER BLADES TO OPERATE ON HILLS • Disengage at tach ment clutch con trol. CAUTION: Do not drive up or down CAUTION: Do not operate the mower hills with slopes greater than 15° and do not drive across any slope. without either the en tire grass catcher, on mowers so equipped, or the deflector shield •...

  • Page 12: Before Starting The Engine

    OPERATION TO START ENGINE (See Fig. 3) SERVICE REMINDER/HOUR METER When starting the engine for the first time or if the engine Service reminder shows the total number of hours the has run out of fuel, it will take extra cranking time to move engine has run and indicates when the engine or mower fuel from the tank to the engine.

  • Page 13: Operation

    OPERATION MOWING TIPS PURGE TRANSMISSION • Tire chains cannot be used when the mower hous ing CAUTION: Never engage or disengage is attached to tractor. freewheel lever while the engine is run ning. • Mower should be properly leveled for best mowing performance.

  • Page 14: Maintenance Schedule

    MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE EACH SEASON STORAGE SCHEDULE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Clean Debris Off Steering Plate ck Transaxle Cooling...

  • Page 15: Maintenance

    MAINTENANCE TRACTOR BLADE CARE For best results mower blades must be kept sharp. Re place Always observe safety rules when per form ing any bent or damaged blades. main te nance. CAUTION: Use only a replacement blade ap- BRAKE OPERATION proved by the manufacturer of your tractor.

  • Page 16: Clean Air Screen

    MAINTENANCE V-BELTS LOWER Check V-belts for deterioration and wear after 100 hours DASH of operation and replace if necessary. The belts are not COVER ad just able. Re place belts if they begin to slip from wear. TRANSAXLE COOLING FASTENER SLOTS The transmission fan and cooling fins should be kept clean to assure proper cooling.

  • Page 17: Engine Cooling System

    MAINTENANCE ENGINE COOLING SYSTEM CLUTCH/BRAKE PEDAL To ensure proper cooling, make sure the grass screen, cooling fins, and other external surfaces of the engine are CLEAN TOP SIDE kept clean at all times. Every 100 hours of operation (more often under extremely dusty, dirty conditions), remove the blower housing and other cooling shrouds.
  • Page 18 MAINTENANCE DECK WASHOUT PORT (See Fig. 20) Your tractor’s deck is equipped with a washout port on its surface as part of its deck wash system. It should be utilized after each use. 1. Drive the tractor to a level, clear spot on your lawn, near enough to a water spigot for your garden hose to reach.

  • Page 19: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •...

  • Page 20: Service And Adjustments

    SERVICE AND ADJUSTMENTS • ATTACH MOWER SIDE SUSPENSION ARMS (A) TO • Insert end of link (E) into hole in front mower bracket CHASSIS - Position hole in arm over pin (B) on outside and secure with washer and retainer spring (J). of tractor chassis and secure with retainer spring.
  • Page 21 SERVICE AND ADJUSTMENTS TO LEVEL MOWER • If adjustment is necessary, see step in Visual Adjust- ment instructions above. Make sure tires are properly inflated to the PSI shown on • Recheck measurements, adjust if necessary until both tires. If tires are over or under inflated, it may affect the sides are equal.

  • Page 22: To Replace Mower Blade Drive Belt

    SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE DRIVE BELT TO REPLACE MOTION DRIVE BELT (See Fig. 31) (See Fig. 32) Park the tractor on level surface. En gage parking brake. The mower blade drive belt may be replaced without tools. For as sis tance, there is a belt installation guide decal on Park the tractor on level surface.
  • Page 23 SERVICE AND ADJUSTMENTS TO REMOVE WHEEL (See Fig. 33) TO REMOVE CABLES, REVERSE ORDER - • BLACK cable first from chassis and then from the fully • Block up axle securely. charged battery. • Remove axle cover, retaining ring and washers to allow •...

  • Page 24: Service And Ad Just Ments

    SERVICE AND ADJUSTMENTS TRANSMISSION TO REPLACE HEADLIGHT BULB • Raise hood. REMOVAL/RE PLACE MENT • Pull bulb holder out of the hole in the backside of the grill. • Replace bulb in holder and push bulb holder securely Should your transmission require removal for service or back into the hole in the backside of the grill.

  • Page 25: Storage

    STORAGE ENGINE Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK...

  • Page 26: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE CORRECTION 1. Out of fuel. 1. Fill fuel tank. Will not start 2. Engine not “CHOKED” properly. 2. See “TO START ENGINE” in Operation section. 3. Engine flooded. 3. Wait several minutes before attempting to start. 4. Bad spark plug. 4.
  • Page 27 TROUBLESHOOTING PROBLEM CAUSE CORRECTION Engine continues 1. Faulty operator-safety presence control 1. Check wiring, switches and connections. If not system. corrected, contact an authorized service center/ to run when oper- department. ator leaves seat with attachment clutch engaged 1. Worn, bent or loose blade. 1.

  • Page 29: Français
