3 • Assembling and Hanging the Fan
Standard or Angle Mounting
Steps 3-2 – 3-3
Set Screw
Low Profile Mounting
Steps 3-5 – 3-6
Green
Ground

Wire
Canopy
Trim Ring
Low Profile Screw
Step 3-6 (Detail)
Adapter
Hunter Fan Company
3-1. Unbundle the wires from the fan.
Downrod
For Standard or Angle mounting:
3-2. Insert the downrod through the canopy and canopy trim ring.
Canopy
Canopy
3-3. Loosen the square head set screw on the adapter to install the
Trim Ring
Low Profile Screws
Low Profile
Washer
For Low Profile mounting:
Canopy
3-4. Remove the set screw from the adapter.
3-5. Place the low profile washer into the canopy with the lip down.
3-6. Align the holes in the washer with the holes in the adapter.
Hanging the Fan:
Note: To hang the fan, you must tilt the canopy to an almost vertical
position so that the canopy slots sit on the ceiling plate hooks.
Low Profile Screw
3-7. Raise the fan and align the slots in the canopy with the hooks on
Low Profile
Washer
3-8. Place the slots over the hooks to hang the fan.
WARNING: Fan may fall if not assembled as directed in these
installation instructions.
Feed the wires from the fan through the downrod on one side of
the pin in the ball.
pipe and ball assembly. Note: When the pipe and ball assembly
is fully installed, 2-3 threads on the pipe will still be visible; this is
normal. Securely retighten the set screw with a wrench or pliers.
Skip to step 3-7.
CAUTION: The adapter has a special coating on the threads. Do
not remove this coating; the coating prevents the downrod from
unscrewing. Once assembled, do not remove the downrod.
Note: For low profile mounting, the downrod is replaced with the
low profile washer.
Assemble securely with three low profile screws.
the ceiling plate.
42741-01 • 1/25/07
