- Page 1 Owner’s Manual MODEL: HSS-NG-SS IMPORTANT Read this manual carefully before assembling, using or servicing this heater. Keep this manual for future reference. ANSI Z83.26-2007/CSA 2.37-2007 Gas-Fired Outdoor Infrared Patio Heaters...
-
Page 2: Table Of Contents
Contents DANGER General Safety Information........1 DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Assembly Instructions Components & Hardware........3 WARNING Additional Requirements ........WARNING indicates an imminently hazardous situation which, if not avoided, could result in death or serious injury. Installation Process CAUTION Step1 - Attach Ground Fixer To Base ..... - Page 3 DANGER DANGER • EXPLOSION - FIRE HAZARD • Keep solid combustibles, such as building materials, • CARBON MONOXIDE HAZARD paper or cardboard, a safe distance away from the heater • This heater is a combustion appliance. All combustion as recommended by the instructions. appliances produce carbon monoxide (CO) during the •...
-
Page 4: Assembly Instructions
Assembly Instructions WARNING Components • This product is fueled by propane gas. Propane gas is invisible, odorless, and flammable. An odorant is normally Remove all components from package. added to help detect leaks and can be described as a Reflector Panel(3) “rotten egg”... -
Page 5: Additional Requirements
WARNING Installation process California Proposition 65 Combustion by products produced when using Step 1 – Attach Ground Fixer To Base this product contain chemicals known to the state of California to cause cancer, birth defects, and other reproductive harm. To protect heater from strong wind, anchor the base securely to the ground with screws. -
Page 6: Step 3 -Attach Post To Post
Fully tighten all of the screws. Step 4 – Attach Reflector Studs to Screen Cover Insert 3 Reflector Studs & 3 Flat Washers. Tighten studs securely. 3 Req’d Reflector Studs 3 Req’d Large Flat Washers Step 3 – Attach Post to Post Attach lower post and upper post to the each end of middle post.Using 4 screws to fasten them. -
Page 7: Step 6 - Install Reflector
Load Head Assembly by inserting hose into post. Insert Head Assembly into post. Control knob should be above decal on post. 9 Req’d Small Screw s 9 Req’d Cap Nuts 9 Req’d Small Flat Washers Slide one Small Flat Washer over threaded end of screw and screw on Cap Nut loosely. -
Page 8: Step 7 - Attach Reflector Assembly To Studs
Step 8 – Connect Hose Step 7 – Attach Reflector Assembly to Studs Support Heater. You must provide natural gas . Slide 3 Large Flat Washers over threaded end of Studs. Use this heater only with a natural gas vapor withdrawal supply system. -
Page 9: Leak Check
Leak Check Operation WARNING DANGER • Perform all leak tests outdoors. • Extinguish all open flames. • CARBON MONOXIDE HAZARD • NEVER leak test when smoking. • For outdoor use only. Never use inside house, or other • Do not use the heater until all connections have been leak unventilated or enclosed areas. -
Page 10: Before Turning Gas Supply On
Push in gas Control Knob and turn counterclockwise Before Turning Gas Supply ON: to “IGNITER” then to “PILOT” (Figure b) to light the pilot. If needed, keep depressing and turning Control Knob Your heater was designed and approved for outdoor counterclockwise until the pilot lights (You should heater use only. -
Page 11: Operation Checklist
Shut Down: experience ignition problem please consult “Troubleshooting” on page 11. Turn Control Knob clockwise to Pilot. (Normally, burner will make a slight popping sound when Caution: Avoid inhaling fumes emitted from the extinguished.) Burner will extinguish but Pilot will remain ON. -
Page 12: Troubleshooting
Troubleshooting If the problem is: And this condition exists: Then do this Cylinder valve is closed Open valve Blockage in orifice or pilot tube Clean or replace orifice or pilot tube Open gas line and bleed it (pressing control Pilot won’t light Air in gas line knob in) for not more than 1 - 2 minutes or until you smell gas... -
Page 13: Storage
Heater’s warranty extends for 1 years from date of purchase by original purchaser. TIP: Manufactured by: Jiangsu Gardensun Furnace Co., Ltd. No. 1, Boyi Town, Use high-quality automobile wax to help maintain the Changzhou City, Jiangsu Province P.R. China. appearance of your heater. Apply to exterior surfaces from...
