Gas-Fired Outdoor Infrared Patio Heaters
US
1
DANGER
WARNING
WARNING:
For Outdoor Use Only
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odor. Using it in an enclosed
space can kill you. Never use this
appliance in an enclosed space
such as a camper, tent, car or
home.
WARNING
ANS Z83.26-2014 • CSA 2.37-2014
Owner's
Manual
OUTDOOR
PATIO HEATER
MODEL #NCZH-G-SS
Advertisement
Table of Contents
Related Manuals for Changzhou Gardensun Furnace NCZH-G-SS
Summary of Contents for Changzhou Gardensun Furnace NCZH-G-SS
- Page 1 Owner’s Manual OUTDOOR PATIO HEATER MODEL #NCZH-G-SS DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.
-
Page 2: Package Contents
PACKAGE CONTENTS Reflector Panel Reflector Plate Head Assembly Cylinder Housing Gas Hose Regulator Upper Pole Lower Pole Support Bracket Base... -
Page 3: Safety Information
HARDWARE CONTENTS (shown actual size) Screw Stainless Flange M6 x 10 steel bolt Bolt Qty. 15 Qty. 9 Qty. 4 Reflector M8 x 16 Bolt Qty. Qty. 9 spacer Qty. 3 M6 x 30 Qty. 3 Qty. Wrench Screw Bolt M6 x 10 Qty. - Page 4 SAFETY INFORMATION DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This heater is a combustion appliance. All paper or cardboard, a safe distance away from the combustion appliances produce carbon monoxide heater as recommended by the instructions.
-
Page 5: Burn Hazard
SAFETY INFORMATION WARNING WARNING California Proposition 65 • This product is fueled by propane gas. Propane gas Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a “rotten egg”... - Page 6 ASSEMBLY INSTRUCTIONS WARNING This product contain sharp edges on the panels cylinder housing and handle please install with care. 1. Reverse the base (J), fix the ground fixer (LL) to the base Secure the ground fixer (LL) with two nuts M6 (NN). Fix another two ground fixer (LL) with bolts and nuts, and reverse the base (J).
- Page 7 ASSEMBLY INSTRUCTIONS 4. Install pole onto three support brackets. Attach pole to support brackets using six bolts M6 x 30 (DD) & six M6 flange nuts (BB). Fully tighten all of the screws. Hardware Used M6 Flange nut Bolt M6 x 30 5.
- Page 8 ASSEMBLY INSTRUCTIONS 7. Unscrew stainless steel bolts M6 x 10 (CC) from head assembly. Hardware Used Stainless steel bolt M6 x 10 8. Insert hose of head assembly into pole. Secure head assembly to pole with stainless steel bolts. Note: The control knob on head assembly should be above the decal on pole.
- Page 9 ASSEMBLY INSTRUCTIONS 10. Slide two reflector panels together. Insert one screw M6 x 10 M6 x 10 (HH) and screw on cap nut (II) loosely. Hardware Used Screw M6 x 10 Cap nuts 11. Slide reflector plate onto reflector panels. Insert one screw M6 x 10 (HH).
- Page 10 ASSEMBLY INSTRUCTIONS 13. Connect hose and regulator to cylinder. The propane gas and cylinder are sold separately. Use a standard 20 lb. propane cylinder only. Use this heater only with a propane vapor withdrawal supply system. See chapter 5 of the standard for storage and handling of liquefied petroleum gas, ANS /NFPA 58.
- Page 11 ASSEMBLY INSTRUCTIONS A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your cylinder supplier. Never use a propane cylinder with a damaged valve connection. The propane cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S.
- Page 12 OPERATION INSTRUCTIONS Leak Check WARNING • Perform all leak tests outdoors. • Extinguish all open flames. • NEVER leak test when smoking. • Do not use the heater until all connections have been leak tested and do not leak. Hose / Regulator Regulator / Cylinder connection connection...
- Page 13 OPERATION INSTRUCTIONS DANGER • CARBON MONOXIDE HAZARD • For outdoor use only. Never use inside house, or other unventilated or enclosed areas. This heater consumes air (oxygen). Do not use in unventilated or enclosed areas to avoid endangering your life. Caution: Do not attempt to operate until you have read and understand all General Safety Information in this manual and all assembly is complete and leak checks have been performed.
- Page 14 OPERATION INSTRUCTIONS Lighting: 1. Turn on the valve on the gas cylinder. 2. Press and turn the control knob to HIGH (maximum) position (counter-clockwise 90º). (Figure 1) 3. Holding down the control knob, press the igniter button several times until the main flame is ignited. Release the control knob 10 seconds after the ignition.
-
Page 15: For Your Safety
OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this heater. Holding in the control know for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When Heater is ON: Emitter screen will become bright red due to intense heat. -
Page 16: Care And Maintenance
OPERATION INSTRUCTIONS 9. Heater is away from gasoline or other flammable liquids or vapors. 10. Heater is away from windows, air intake openings, sprinklers and other water sources. 11. Heater is at least 3 feet on top and at least 3 feet on sides from combustible materials. 12. - Page 17 CARE AND MAINTENANCE Signs of possible blockage include: Gas odor with extreme yellow tipping of flame. Heater does NOT reach the desired temperature. Heater glow is excessively uneven. Heater makes popping noises. Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater and render it unsafe for use.
-
Page 18: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Wait until the propane cylinder Propane cylinder is frosted over warms up and is defrosted Burner won’t light Blockage in orifice Clear blockage Control knob is not in ON position Turn control knob to ON Turn cylinder valve OFF and replace Gas pressure is low cylinder... -
Page 19: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This product is inspected, tested and carefully packaged to minimize the chance of damage during shipment. If a part within one year from the date of purchase proves to be defective in material or fabrication under normal use, the part will be repaired or replaced. The Company's obligation under the warranty is to replace or repair defective parts at our discretion. -
Page 20: Replacement Parts List
REPLACEMENT PARTS LIST Reflector Panel Reflector Plate Head Assembly Cylinder Housing Gas Hose Regulator Upper Pole Lower Pole Support Bracket Base Printed in China...
