AR8200D
(Upgraded AR8200MK3)
Wide Range Handheld Receiver
Operating manual addendum
AOR, LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AR8200D and is the answer not in the manual?

Questions and answers

Related Manuals for AOR AR8200D

Summary of Contents for AOR AR8200D

  • Page 1 ® AR8200D (Upgraded AR8200MK3) Wide Range Handheld Receiver Operating manual addendum AOR, LTD.

  • Page 2: Additional Functions

    5. USB interface 1 VOICE RECORDING The AR8200D has a built-in SD memory card interface used for voice recording. The recording may be played back over and over. The recorded files are in wav format and can be played back using a PC.
  • Page 3 4. To stop recording, press and hold the [CONTROL] switch again for two seconds. The red LED will go off. 1-2 Playback Before playing back audio files, perform the following steps: 1. Set the receiver to “Voice Inverter” mode. [Note: The voice inverter function is disabled with US consumer version even though the menu is displayed on the LCD].
  • Page 4 To stop, press and hold the [CONTROL] key for two seconds. The red LED will go off. 1-3 File management To edit or delete recorded files, remove the SD card from the AR8200D and insert it into your PC using the adapter. The AR8200D unit does not have the file management function.
  • Page 5 beeps). APCO25  Voice Inverter  CTCSS  APCO25  ……… 3. To select the CTCSS mode, press and hold the [CLEAR] key for two seconds. 4. “CTCSS OFF ON SRCH” will appear on the LCD. 5. Use the UP / DOWN arrow key to select “ON”. 6.
  • Page 6 94.8 100.0 103.5 107.2 110.9 114.8 118.8 123.0 127.3 131.8 136.5 141.3 146.2 151.4 156.7 162.2 167.9 173.8 179.9 186.2 192.8 203.5 210.7 218.1 225.7 233.6 241.8 250.3 67.0 71.9 74.7 77.0 79.7 82.5 85.4 88.5 91.5 97.4 69.4 159.8 165.5 171.3 177.3...
  • Page 7 4. “VOICE INVERT ON / OFF” will appear on the LCD. 5. Rotate the dial knob or use the RIGHT / LEFT ARROW key to select the desired inversion frequency / value from the list below. The selected inversion value will be displayed on the LCD. 7.

  • Page 8: Usb Interface

    5 USB INTERFACE The mini USB connector located on the digital control unit is designed to connect directly to the USB port of a PC. All FUNCTIONs of the AR8200D can be controlled by a PC by using the USB interface.
  • Page 9 5-1 USB driver Before connecting the AR8200D to a PC, the USB driver for the AR8200D must be installed. The USB driver can be downloaded from the manufacturer’s website. http://www.ftdichip.com/ftdrivers.htm Click “VCP Drivers”, and then select the device name “FT232B”.
