6.2 Connecting the projector to a computer

1) Plug the VGA cable into the VGA port at the left side of projector then plug
the other end of VGA cable into the computer.
Note:
If you are connecting to a notebook, you may need to make adjustments to
the notebook's display settings first. Please refer to the user's guide that
came with your notebook.
2) If you want to use the remote control as a mouse, plug the USB cable into the
USB port at the left side of projector, then plug the other end into the computer.
3) If your presentation contains audio, plug the PC Audio in/out cable into the
Audio In port at the left side of projector, then plug the other end into the
computer.
4) Turn on the projector first, then the computer.

6.3 Connecting the projector to a Video Source

If you are using a composite video source, refer to the following:
1) Plug the yellow, red, and white RCA connectors separately into the
appropriately colored port at the left side of projector.
2) Plug the yellow, red, and white connectors on the other end into the
corresponding ports on the Video Source.
If you are using an S-video source, refer to the following:
1) Plug the S-Video cable connector into the S-Video port at the left side of
projector then plug the other end into the Video
2) Plug the red and white connectors from the composite video cable into the
corresponding ports at the left side of projector, then plug the other end into the
corresponding ports on the Video Source.
Note:
When you are using the S-Video cable along with the A/V cable, do not plug in
the A/V cable's yellow connector
Source.
.
