- Page 1 AtlonA HDMI Repeater Accessory Unit AT-PROHD-RP Accessory to Atlona’s 8x8:2 Matrix Switch (AT-PROHD88M-SR) User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction ..........2. Features ..........3. Package Contents ..........4. Panel Descriptions ..........5. Operation ..........6. Specifications ..........7. Safety Information ..........8. Warranty ..........9. Atlona Product Registration .......... -
Page 3: Introduction
Atlona Technologies’ AT-PROHD-RP is a HDMI Repeater to be used with the AT-PROHD88M- SR, Atlona’s Pro 8x82 Matrix Switcher. This HDMI Repeater is designed to use cost effective CAT-5E/6 cable in order to extend HD signal long distances without degradation. These dis- tances include 50 meters (164ft) for 1080p and 60 meters (196ft) for 1080i. -
Page 4: Panel Descriptions
1) Connect two CAT-5E cables with both outputs of Main Sender Unit (AT-PROHD88M-S) with the CAT-5E inputs of the Repeater unit (AT-PROHD-RP). 2) Connect the two CAT-5E cables with both outputs of Repeater Unit (AT-PROHD-RP) with the inputs of Main Receiver Unit (AT-PROHD88M-R) -
Page 5: Specifications
SPECIFICATIONS Input Video Signal 0.5-1.0 volts Input DDC Signal 5 volts p-p (TTL) Video Formats Supported DTV/HDTV; 1080P/1080i/720P/576P/480P/576i/480i Output Video HDMI 1.3,HDCP Output Audio Supported DTS-HD, Dolby-HD Transmission Distance up to 50m (164ft) Power Supply 5VDC Power Use 1.5Watts (Max) Dimensions 1.8’’W×3.3’’H×0.9’’D IR frequency... -
Page 6: Safety Information
Use only accessories recommended by ATLONA to avoid fire, shock or other Do not modify the wall plug. hazards. Doing so will void the warranty and safety features. -
Page 7: Warranty
Product, or repair or replacement of the Product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. -
Page 8: Atlona Product Registration
At Atlona, we respect and protect your privacy and assure you that your registration information is completely secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited warranty rights. To register go to www.atlona.com/registration...
