QuickSpecs
Overview (availability varies by configuration and by country)
1. External 5.25" drive bay for optional optical drive
2. Internal 3.5" hard drive bay
3. Power supply
4. Rear I/O includes: USB 2.0 ports (see page 7);
network, video, audio, and other interfaces (see page 7)
5. PCIe, and MiniCard slots (select models) See page 7 for
details.
At A Glance
At A Glance
At A Glance
At A Glance
Genuine Windows 7 versions, Genuine Windows Vista versions, Genuine Windows XP Professional available through
downgrade rights from Windows 7 Professional, SuSE Linux Enterprise Desktop 11, or FreeDOS
Choice of Intel® processor (varies by model)
Choice of integrated graphics or ATI or NVIDIA graphics cards
Up to 8 GB (HP Pro 3120) or 16 GB (HP Pro 3130) DDR3 SDRAM system memory available standard
Up to 2 TB 3.0 Gb/s SATA hard drive
HP SuperMulti LightScribe DVD Writer
Integrated Realtek 8111DL Gigabit Ethernet Controller
HP Wireless 802.11 b/g/n
HP USB Internal Bluetooth module
USB 2.0 ports
VGA and DVI-D video ports
Legacy serial and PS/2 ports (HP Pro 2110 only)
Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.
HP Pro 2100/3100 Series Small Form Factor Business
HP Pro 2100/3100 Series Small Form Factor Business
HP Pro 2100/3100 Series Small Form Factor Business
HP Pro 2100/3100 Series Small Form Factor Business
DA - 13641
Worldwide — Version 5 — March 2, 2011
6. Front I/O includes: (2) USB 2.0 ports, dedicated headphone
output, and microphone jack
7. HP USB Scroll Mouse
8. HP USB Keyboard
9. Monitor (sold separately)
PCs
PCs
PCs
PCs
Page 1

Advertisement

loading

  Related Manuals for HP Pro 2100 Series

  Summary of Contents for HP Pro 2100 Series

  • Page 1 Choice of Intel® processor (varies by model) Choice of integrated graphics or ATI or NVIDIA graphics cards Up to 8 GB (HP Pro 3120) or 16 GB (HP Pro 3130) DDR3 SDRAM system memory available standard Up to 2 TB 3.0 Gb/s SATA hard drive...
  • Page 2 Intel Celeron E3300 Processor (2.5 GHz, 1 MB L2 cache, 800 MHz FSB) Intel Pentium® Dual Core Processors (HP Pro 2110 and 3120 only): Intel Pentium® Dual Core Processors (HP Pro 2110 and 3120 only): Intel Pentium® Dual Core Processors (HP Pro 2110 and 3120 only): Intel Pentium®...
  • Page 3 QuickSpecs HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business Standard Features (availability varies by configuration and by country) Intel Core i5-750 Processor* (2.66 GHz, 8 MB Intel Smart Cache, DMI 2.5 GT/s)
  • Page 4 Integrated Intel Graphics Media Accelerator HD NOTE: NOTE: NOTE: NOTE: HP Pro 3130 with any Intel Core i7 processor or an Intel Core i5-750 processor has no integrated graphics and requires a graphics card. Graphics Cards Graphics Cards Graphics Cards...
  • Page 5 QuickSpecs HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business Standard Features (availability varies by configuration and by country)
  • Page 6 3120 3120 3130 3130 3130 3130 Front Rear Optional HP USB 3.0 SuperSpeed low profile PCIe x1 card Interfaces Interfaces Interfaces Interfaces One (1) analog VGA video port One (1) DVI-D video port HP Pro 2110 One (1) RJ45 network port One (1) audio in;...
  • Page 7 Audio Audio Audio Audio Realtek ALC662 High Definition audio codec in HP Pro 2110 Realtek ALC888S High Definition audio codec in HP Pro 3120 and 3130 Input Devices Input Devices Input Devices Input Devices Keyboard – One of the following Keyboard –...
  • Page 8 NOTE 2: NOTE 2: NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.

  • Page 9: After-Market Options (Availability Varies By Configuration And By Country)

    QuickSpecs HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business After-Market Options (availability varies by configuration and by country)
  • Page 10 QuickSpecs HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business HP Pro 2100/3100 Series Small Form Factor Business After-Market Options (availability varies by configuration and by country)

  • Page 11: System Unit Specifications

    Maximum Altitude Operating 10,000 ft (3048 m) (unpressurized) Non-operating 30,000 ft (9144 m) For accessibility information on HP products, please visit: http://www.hp.com/accessibility. Unit Environment and Unit Environment and Unit Environment and Unit Environment and General Unit Operating Guidelines General Unit Operating Guidelines...
  • Page 12 IT ECO declaration HP Pro 2110 Small Form Factor Business PC, HP Pro 3120 Small Form Factor Business PC and HP HP Pro 2110 Small Form Factor Business PC, HP Pro 3120 Small Form Factor Business PC and HP...
  • Page 13 By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
  • Page 14 HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

This manual is also suitable for:

Pro 3100 series
